ADLINK Technology COM Express cExpress-TL User Manual page 23

cExpress-TL User's Guide
Row A
A106 VCC_12V
A107 VCC_12V
A108 VCC_12V
A109 VCC_12V
A110 GND (FIXED)
Note: STRIKETHROUGH strike-through entries are not supported functions on this product.
PCIe lane 5,6,7 are BOM option support (through a PCIe switch) by project basis.
eDP (in place of LVDS) and VGA (in place of DDI 3) are BOM option support by project basis.
Ethernet support up to 2.5GbE. The LAN LED behavior (GBE0_LINK 100#, GBE0_LINK1000#) is optimized based on maximum 2.5GbE speed
(see 4.3.4 Gigabit Ethernet on page
Page 23
Row B
B106 VCC_12V
B107 VCC_12V
B108 VCC_12V
B109 VCC_12V
B110 GND (FIXED)
30).
Copyright © 2021 ADLINK Technology, Inc.
Row C
C106 VCC_12V
C107 VCC_12V
C108 VCC_12V
C109 VCC_12V
C110 GND (FIXED)
PICMG COM.0 R3.0
Row D
D106 VCC_12V
D107 VCC_12V
D108 VCC_12V
D109 VCC_12V
D110 GND (FIXED)
