Chapter 4 Connecting computers and other devices
Sharing USB Type-B receptacles
The HDMI and VGA connectors on the connector panel share USB Type-B receptacles:
USB Type-B receptacle
Touch 1
Touch 2
If two computers are connected to video connectors that share the same USB Type-B receptacle, you
must disconnect the USB cable from the first computer and connect it to the second computer if you
want to switch from one computer's input to the other's. For example, if a room computer is connected to
HDMI 1 and a guest laptop is connected to HDMI 2, you must disconnect the USB cable from the room
computer and connect it to the guest laptop when you want to switch to the guest laptop's input.

Connecting a SMART OPS PC module

If your organization has purchased a SMART OPS PC module, you or your
organization's installers can install the OPS PC module in the display's
accessory slot following the OPS PC module's installation instructions
(smarttech.com/kb/171544). You can then view the OPS PC module's input on
the display.
For more information about SMART OPS PC modules, see the SMART OPS PC
modules user guide (smarttech.com/kb/171747).
smarttech.com/kb/171539
Video connectors
HDMI 1
l
HDMI 2
l
HDMI 3
l
VGA
l
