Addendum to the Sympodium® DT770 Interactive Pen
Display Installation Guide
This addendum contains information about the DT770 interactive pen display that was not
included in the Sympodium DT770 Interactive Pen Display Installation Guide, including:
• mounting the DT770 on a mono stand (this page)
• using the DT770 with a Mac computer (page 2)

Mounting the DT770 on a Mono Stand

If you want to mount the DT770 at an angle of 30° or 45° degrees, you can install the DT770 on
the supplied mono stand.
To install the DT770 on the mono stand
1. Place the DT770 facedown on a flat surface.
CAUTION
2. Loosen the four captive screws in the mono stand.
3. Align the captive screws in the mono stand with the four holes on the back of the interactive
pen display.
Top Edge of
the DT770
If you want the DT770 to be on a 30°
angle, align the mono stand so the
vertical part of the stand is near the top
edge of the DT770.
Addendum to the Sympodium DT770 Interactive Pen Display Installation Guide
Place the DT770 down slowly and carefully to ensure you don't damage the
buttons.
Don't place the DT770 on a surface that will mark, scratch or damage the
screen or its optical components.
If you want the DT770 to be on a 45°
angle, align the mono stand so the
vertical part of the stand is near the
bottom edge of the DT770.
Bottom Edge
of the DT770
