OSD NETWORKS OSD2258EP Operator's Manual page 55

C
ONFIGURATION
IGMP Snooping Configuration
IGMP S
NOOPING
A drop-down menu allows user settings for the following;
•
•
U
NREGISTERED
A drop-down menu allows user settings for the following;
•
•
Port Related Configuration
P
ORT
Displays port number per row
S R
TATIC OUTER
A drop-down menu allows user settings for the following;
•
•
Buttons
: saves the new settings
PAGE 55
→ IGMP
Enable: Enables IGMP Snooping
Disable: Disables IGMP Snooping
M F
ULTICAST LOODING
Enable: Enables Unregistered Multicast Flooding. The unregistered
IPMCv4 traffic will be forwarded to all other ports as broadcast traffic
Disable: Disables Unregistered Multicast Flooding. The unregistered
IPMCv4 traffic will not be received on other ports when IGMP function is
enabled
P
ORT
Enable: Enables IGMP Static Router setting
Disable: Disables IGMP Static Router setting
OSD2258EP Operator Manual
10119802
