1 TECHNICAL SUMMARY

1.1 BRIEF DESCRIPTION

1.1.1 OVERVIEW
The OSD2258EP is a 10-port lite managed industrial ethernet switch with eight Gigabit RJ45 and two
Gigabit SFP uplink ports which can be used as standard ports or as a redundant fiber ring using OSD's
proprietary ring protocol. Each RJ45 can provide up to 60W PoE to power a wide range of devices. Along
with higher level features including SNMP, VLAN and IGMP snooping the OSD2258EP is suitable for use
in critical networks. A rugged IP30 casing, fan-less design and wide operating temperature range from -40
to +75ºC make it suitable for use in a wide range of harsh industrial environments.
1.1.2

FEATURES AND BENEFITS

▲ Complies with IEEE802.3i/802.3u/ 802.3ab
10/100/1000Base-T, IEEE802.3z
1000Base-Lx/Sx standards
▲ Has a total of ten ports: eight fixed copper
ports for 10/100/1000Base-T and two SFP
ports for the fiber ring or non-ring
(1000Base-X)
▲ A network diameter of hundreds of
kilometers is practical
▲ Ring reconfiguration in the case of cable or
switch failures takes less than two
milliseconds per hop
▲ MDI/MDIX Crossover: no need for
crossover cables
▲ Can be used with either 1 or 2 singlemode
or multimode fiber over a variety of link
budgets via plug in SFP module (sold
separately)
▲ Supports IEEE802.3af/at Alternative A and
B cable wiring
▲ Complies with IEEE802.3af/at standard
including compliant powered device (PD)
signature detection and classification
▲ Customisable PoE via DIP switch or GUI
providing up to 60W to each RJ45 port
supporting both single signature and dual
signature PD detection
PAGE 5
OSD2258EP Operator Manual
▲ Auto-Negotiation for half or full duplex
operation
▲ Supports 10KB jumbo frames
▲ Powered by non-critical 46 to 57V
supplies, ie redundant power inputs
▲ Integrates with third party NMS system via
industry standard SNMP v1, v2c, v3
▲ Supports VLAN and IGMP v1, v2, v3
snooping
▲ Port security guaranteed with MAC binding
function
▲ Remote PoE on/off control and status
monitoring
▲ Operates over the temperature range of -
40°C to +75°C
▲ Web browser GUI included
▲ Compatible with the OSD22XX series of
redundant ring Gigabit Ethernet switches
▲ Available for operation in ring, bus or point-
to-point configuration
▲ DIN rail or wall mounting
