2.4.2

COMMAND LINE FUNCTIONS

There are a number of command line functions that enables the user to obtain running
information of a single OSD2258EP unit or the complete topology of the ring/bus network.
This section explains the command lines and its functions.
When the terminal emulation program is operating, connect the USB cable to any one of the
OSD2258EP units on the ring/bus network – or alternatively, the OSD2258EP unit which the
user wishes to interrogate. Note: A message will be displayed on the terminal emulation
program when the unit is powered after USB connection. This message will not open when
the unit is switched on while plugging in the USB cable, however the command lines are
functional.
The following table outlines the user available command line commands and their functions.
TERMINAL
COMMAND
LINE
?
vc
poe_mode
fd
ipconfig
tc
nc
lnc
fbe
fbd
node_ip_set
node_all_set
reboot
config_snmp
portctrl
portsecurity
PAGE 21
TABLE 6: TERMINAL COMMAND LINES

SPECIFICATION

Lists all CLI commands including
Help
input format information
Displays the current software
Version Check version and revision installed on the
unit
Sets ports 5-8 Poe channel
PoE Mode detection and power output
configuration
Reset configuration to factory
Factory Default
default
IP Configuration Configure the IP address
Displays the topology status of the
Topology Check
established ring/bus
Gets running status of the node for
Node Check
given MAC address
Gets running status of the local
Local Node Check
node
Float Backup Enable float backup function for all
Enable nodes in a Ring/Bus
Float Backup Disable float backup function for all
Disable nodes in a ring/bus
Setup IP of the node with given
Node IP Set
MAC address
Node All Set Setup IP for all nodes on a ring/bus
Reboot Reboot the device in the network
Configure SNMP Change to SNMP sub menu
Port Control Enables/Disables all ports
Change to Port Security
Port Security
configuration sub menu
OSD2258EP Operator Manual
FUNCTION FIGURE
-
Figure 18
Figure 19
Figure 20
Figure 21
Figure 22
Figure 24
Figure 25
Figure 26
Figure 30
Figure 33
Figure 34
Figure 35
Figure 36
Figure 38
Figure 39
