2.2.9 CONTROLS
The OSD2258EP has an 8-way DIP switch to control a number of functions. Table 5 outlines
the function of each switch.
SWITCH
NUMBER
1
2
3
4
5
6
7
8
* Default settings.
Ϯ At Off position and power-up, unit will switch to default settings.
Note: The unit requires a power cycle (Off/On) for any switch position change to take effect.
PAGE 16
FIGURE 11: CONTROLS
ON
1 2
FIGURE 12: 8-WAY DIP SWITCH
TABLE 5: 8-WAY DIP SWITCH SETTINGS
DESCRIPTION
GUI Enabled
GUI Mode
GUI Disabled
PoE Mode [2] See Table 6 for PoE Mode Function
PoE Mode [1] See Table 6 for PoE Mode Function
PoE Mode [0] See Table 6 for PoE Mode Function
Non-Ring
Ring/Bus
Ring
100Mbps
Port 9 Fiber Speed
1000Mbps
100Mbps
Port 10 Fiber Speed
1000Mbps
Erase Mode
Reserved
User Mode
OSD2258EP Operator Manual
3 4 5 6 7
FUNCTION
8-Way DIP Switch
OFF
8
SWITCH
POSITION
ON*
OFF
OFF*
OFF*
OFF*
ON
OFF*
ON
OFF*
ON
OFF*
ON
OFF*
