SATEL
"MONO switch" / "BI switch" / "Remote switch" type output deactivated
"MONO switch" / "BI switch" / "Remote switch" type output activated
"Shutter up" type output deactivated
"Shutter up" type output activated
"Shutter down" type output deactivated
"Shutter down" type output activated
8.5
Temperature
The widget displays the temperature. Information about the temperature is sourced from an
ABAX 2 / ABAX wireless detector.
8.6
Date/time
The widget displays the date and time in the format specified by the installer.
8.7
Switch
The icon for the widget is selected by the installer. Tap the widget to activate / deactivate an
output.
8.8
Rectangle
The widget displays a rectangle that can be translucent and have different colors. As an
additional graphic element it may be used e.g. to highlight a part of the screen.
8.9
Macro
The icon for the widget is selected by the installer. Tap the widget to run a macro command.
The macro command is a sequence of actions to be performed by the control panel. Macro
commands are created by the installer.
8.10 PANIC/FIRE/AUX.
The widget is used to trigger an alarm (
alarm).
8.11 Information
The widget is represented on the screen by the
message prepared by the installer.
8.12 Link
The icon for the widget is selected by the installer. Tap the widget to go to the additional
screen / return to the user screen from the additional screen.
INT-TSH2
- panic alarm;
icon. Tap the widget to view the
- fire alarm;
- medical
11
