SATEL
If the "Grade 2" (INTEGRA) / "Grade 3" (INTEGRA Plus) option is enabled by the
installer:
− information about the alarm is not displayed;
− the
icon indicates trouble / trouble memory / alarm / alarm memory / bypassed
zones.

8. Widgets

The widgets described below may be displayed on the screen.
8.1

Text

The widget displays any text that was added by the installer or system element name.
8.2

Partition state

The widget indicates the partition state by means of the following icons.
Icon
disarmed – there are no violated zones
disarmed – there are violated zones
exit delay is running – remaining time longer than 10 seconds
exit delay is running – less than 10 seconds remained
armed – mode: "full"
armed – mode: "full + bypasses"
armed – mode: "without interior"
armed – mode: "without interior and without entry delay"
temporarily blocked
entry delay is running
fire alarm
alarm
fire alarm memory
alarm memory
first code has been entered (the partition is armed/disarmed using two codes)
INT-TSH2
Partition status
9
