KEYBOARD COMMANDS - Multiple Hotkey Commands
Additional commands
+
HK O
When you simultaneously press hotkey and command key O, unit enters and displays OSD (see Chapter
On Screen Display)
HK V
+
When you simultaneously press hotkey and command key V for longer than 5 seconds, unit sets output video
resolution to 640x 480 pixel at 60 Hz (basic video settings).
+
HK I
When you simultaneously press hotkey and command key I, unit enters PIP menu directly
KEYBOARD COMMANDS - Double Click Hotkey Commands
Selection of Display Mode
HK Q
When you press hotkey and afterwards command key Q, unit switches to Quad Mode or back to last selected
fullscreen channel.
HK F
When you press hotkey and afterwards command key F, unit switches active channel to Fullscreen Mode.
HK P
When you press hotkey and afterwards command key P in Fullscreen Mode, unit enables or disables PiP
(picture in picture) function.
In Quad Mode the Hotkey P is used to open the channel selection window, where the blue selector points to the
active channel. In order to select another channel use Hotkey P repeatedly.
Quad View Switch - Installation and Operation Manual
Entry OSD
Basic output resoluton
Enter PiP Menu
Quad Mode
Fullscreen Mode
PiP Mode (Fullscreen) / Select Channel (Quad)
KEYBOARD COMMANDS
