Dell EMC Edge Gateway 5200 Service Manual page 38

Installation procedure for 2x GbE LAN uFM
About this task
Installation requires the removal of WiFi, as well as COM3 and COM4 ports. The 4-port COM cable will be replaced with an
included dual-port COM cable.
Table 9. Expansion module packing list
Item
Screw M3 x 6L
Screw M3 x 4L
Screw M3 x 5L
Standoff H4
Nut M3
Screw M2.5 x 6L
Cable tie
Rubber cap
Cable clip
Sheet metal I/O panel
Bracket
LAN PCBA
LAN mPCIe
Dual-port COM cable
LAN cable
Steps
1. Remove the eight screws from the bottom panel of the EGW-5200, as shown in the following figure, and remove the bottom
panel.
38 Installation procedure for 2x GbE LAN uFM module
Quantity Notes
2 Torque required: 4.0 kgf.cm
14 Torque required: 4.0 kgf.cm
1 Torque required: 4.0 kgf.cm
4 Torque required: 4.5 kgf.cm
4 Torque required: 4.0 kgf.cm
2 Torque required: 3.0 kgf.cm
2 -
2 -
1 -
1 -
1 -
1 -
1 -
1 -
2 -
V
module
