Installation procedure for 2x GbE with PoE
About this task
Installation requires the removal of WiFi, as well as COM3 and COM4 ports. The 4-port COM cable will be replaced with an
included dual-port COM cable.
Table 8. Expansion module packing list
Item
Screw M3 x 6L
Screw M3 x 4L
Screw M3 x 5L
Standoff H4
Nut M3
Screw M2.5 x 6L
Cable tie
Rubber cap
Cable clip
Sheet metal I/O panel
Bracket
PoE PCBA
PoE mPCIe
Dual-port COM cable
Cable
Thermal pad
Steps
1. Remove the eight screws from the bottom panel of the EGW-5200, as shown in the following figure, and remove the bottom
panel.
Quantity
Notes
2
Torque required: 4.0 kgf.cm
14
Torque required: 4.0 kgf.cm
1
Torque required: 4.0 kgf.cm
4
Torque required: 4.5 kgf.cm
4
Torque required: 4.0 kgf.cm
2
Torque required: 3.0 kgf.cm
2
-
2
-
1
-
1
-
1
-
1
-
1
-
1
-
2
-
1
-
Installation procedure for 2x GbE with PoE uFM module
