When the instrument is in Sense Reverse Protection state, you should check
whether the polarities are connected reversely or not firstly. If yes, you can re-
open the output after the polarities connect correctly.
The voltage difference between output terminal and remote sense terminal of
each model is not the same. When the remote sense terminal is connected re-
versely, the maximum voltage will not exceed the sum of output terminal voltage
and the difference voltage.

4.6 Function Menu for Power Supply

The Function menu of the power supply includes the following:
Function

4.6.1 LIST Function

This series power supply supports a total of 10 List files (List01 to List10), each
of which can be set up to 200 steps. You need to edit the voltage/current value,
slope and time width of each step, or you can set repeat times (1 to 65535) for
each List file. After the file is edited completely, you can trigger the selected List
file to run according to the selected trigger mode.
The descriptions of list function menu are listed in the table below.
LIST
When Sense is reversed or short-circuited, the voltage meter value is dis-
played as a positive/negative value close to 0, and abnormal high voltage
output does not occur, which can avoid damage to the DUT.
Function Menu for Power Supply
LIST
BATTERY
List menu
Run Indicates to enter the List run mode, waiting for the trigger to
run the currently selected List file.
Open Select the List file to open.
Copyright © Itech Electronic Co., Ltd.
LIST program editing, file import/export, pro-
gram running (see 4.6.1 LIST
Battery charging testing function (see
Battery Charging Test
Power Supply Function
Function).
4.6.2
Function).
