Vehicle Connections - Directechs DS3+ Installation Manual

Vehicle connections

The connection information listed below is specific to the 2010 Hyundai Genesis Coupe (Smart Key). Refer to "Pre-installation and application warnings" for a list of important
notes.
Data harness, 8-pin white connector (H1)
Module
Conn./Pin Color Description
H1/1 Tan (Data) HS CAN 1 Low
H1/2 Tan/Black (Data) HS CAN 1 High
H1/3 Orange/Brown (Data) HS CAN 2 Low
H1/4 Orange/Green (Data) HS CAN 2 High
H1/5 Lt. Green No Connection
H1/6 Violet/Brown No Connection
H1/7 Orange/Black No Connection
H1/8 Yellow/Black (-) Keysense Output
Analog input/output harness, 22-pin white connector (H2)
Module
Conn./Pin Color Description
H2/1 Lt. Green/Black (-) Factory Alarm Arm Output
H2/2 Blue/White (-) Ground When Armed (GWA) Output [3]
H2/3 Dk. Green/Black (-) Lock Output
H2/4 Red/White (-) Trunk Release Output
H2/5 Brown/Black (-) Horn Output
H2/6 Brown/White (-) AUX 1 Output
H2/7 White (+) AUX 1 Output
H2/8 Violet/Black (+) AUX 2 Output
H2/9 Dk. Blue/Black (-) Unlock Output
H2/10 Lt. Blue/Black (-) Factory Alarm Disarrn Output
H2/11 Brown/Red (+) Siren Output [2]
H2/12 Pink (+) Ignition Sense Input
H2/13 Violet (+) Door Input
10 933.HYUNDAI1 4.10.195.3 2010 Hyundai Genesis Coupe (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
data link connector, black 16 pin plug, pin 14
data link connector, black 16 pin plug, pin 6
Power Distribution Module right of column, white 20 pin plug,
pin 10
Power Distribution Module right of column, white 20 pin plug,
pin 11
No Connection
No Connection
No Connection
Power Distribution Module right of column, white 20 pin plug,
pin 12
Connects To
Wire Location
No Connection
Starter:
Power Distribution Module right of column, black 10 pin plug,
pin 6
Ignition:
Power Distribution Module right of column, black 10 pin plug,
pin 7
Must use a relay.
Must use a 1N4002 diode or larger.
No Connection
No Connection
driver kick, blue 42 pin plug, pin 11
No Connection
No Connection
No Connection
No Connection
No Connection
Power Distribution Module right of column, black 10 pin plug,
pin 7
No Connection
(+/-) Wire Color Connection
data blue (C-CAN) Mandatory
data red (C-CAN) Mandatory
data blue (B-CAN) Mandatory
data red (B-CAN) Mandatory
- red Remote Start
Only
(+/-) Wire Color Connection
+ white Mandatory
+ blue/orange
- green/orange Optional
Security Only
+ blue/orange Mandatory
