Directechs DS3+ Installation Manual page 12

2010 hyundai genesis coupe (smart key). 933.hyundai1 4.10.195.3
Hide thumbs Also See for Directechs DS3+:
Table of Contents

Advertisement

Module
Conn./Pin
Color
Description
H4/5
Red
(+) 12 Volt Input
H4/6
Green
Starter Disable (key side)
H4/7
Violet
(+) Starter Output (starter side)
H4/8
Orange
(+) Accessory Output
H4/9
Red/White
(+) 12 Volt Input
H4/10
Pink
(+) Ignition Input/Output
RF Port harness, 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
D2D harness, 4-pin white (1) and black (2) connectors (H6)
Module
Conn./Pin
H6/1
H6/2
H6/3
H6/4
Temperature sensor harness, 2-pin black connector (H7)
Module
Conn./Pin
Color
Description
H7/1
Black
Temperature Sensor
H7/2
Black
Temperature Sensor
12
933.HYUNDAI1 4.10.195.3 2010 Hyundai Genesis Coupe (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
Color
N/A
N/A
Color
Blue
Black
Green
Red
Connects To
Wire Location
(+/-)
Wire Color
Description
RF Loop
RF Loop
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
(+/-)
Wire Color
Connection
Connection
