Directechs DS3+ Installation Manual page 11

Module
Conn./Pin Color Description
H2/14 Brown (+) Brake Input
H2/15 White/Blue (-) Activation Input
H2/16 Red/Blue (-) Valet Switch
H2/17 Black/White (-) E-Brake Input
H2/18 Orange/Black (+) Instant Alarm Input
H2/19 Blue (-) Trunk Input
H2/20 Green (-) Door Input
H2/21 Gray (-) Hood Switch Input [1]
H2/22 Violet/White (AC) Tach Input [3]
Main harness, 12-pin black connector (H3)
Module
Conn./Pin Color Description
H3/1 Blue/White Relay N.C. No Connection
H3/2 Blue/Red Relay N.O. (+) 12V Input
H3/3 Blue Relay COM (+) PTS Output
H3/4 White/Brown Relay N.C. No Connection
H3/5 White Relay COM (-) Clutch Output
H3/6 Red (+) 12V Input
H3/7 Lt. Green/Red Relay N.O. (+) 12V Input
H3/8 Lt. Green Relay COM (+) Parking Light Output
H3/9 Lt. Green/White Relay N.C. No Connection
H3/10 Black (-) Ground
H3/11 White Relay COM (-) Clutch Output
H3/12 Red (+) 12V Input
Relay harness, 10-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 N/A No Connection
H4/2 Red/Black (+) 12 Volt Input
H4/3 Pink/Black Flex Relay (pin 87A)
H4/4 Pink/White (+) Flex Relay Output
11 933.HYUNDAI1 4.10.195.3 2010 Hyundai Genesis Coupe (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
No Connection
No Connection
No Connection
dash fuse box, rear, blue 14 pin plug (G), pin 4
No Connection
No Connection
No Connection
Power Distribution Module right of column, white 20 pin plug,
pin 16
Connects To
Wire Location
No Connection
dash fuse box, rear, brown 1 pin plug (K), pin 1
Must use (2) 1A diodes.
start stop button switch, black 10 pin plug, pin 1
start stop button switch, black 10 pin plug, pin 7
No Connection
clutch switch, white 2 pin plug, pin 1
dash fuse box, rear, brown 1 pin plug (K), pin 1
dash fuse box, rear, brown 1 pin plug (K), pin 1
Must use (2) 6A diodes.
dash fuse box, rear, blue 14 pin plug (G), pins 6, 3
No Connection
clutch switch, white 2 pin plug, pin 1
dash fuse box, rear, brown 1 pin plug (K), pin 1
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color Connection
- brown/orange Remote Start
Only
ac white/orange Remote Start
Only
(+/-) Wire Color Connection
+ red (50A) Remote Start
Only
+ blue Remote Start
Only
+ pink
- green Remote Start
Only
+ red (50A) Mandatory
+ red (50A) Mandatory
+ blue (L); blue or gray (R) Mandatory
(chassis ground) Mandatory
- green Remote Start
Only
+ red (50A) Mandatory
(+/-) Wire Color Connection
