Flavor Burst CTP 80SS-DLX Operation Manual Supplement

Deluxe cabinet
Hide thumbs Also See for CTP 80SS-DLX:
Table of Contents

Advertisement

Quick Links

Download this manual
Flavor Burst
®
Deluxe Cabinet
- Operations Manual Supplement
Models: CTP 80SS-DLX
CTP 80BLD-DLX
CTP 80CBB-DLX
CTP 80BEV-DLX
CTP 80FCB-DLX
SS-DLX
Manufactured by
Flavor Burst Company
499 Commerce Drive
Danville, IN 46122
For general information and to locate a
distributor near you, call or visit our
website:
Phone: (317) 745-2952
Toll Free Number: (800) 264-3528
Fax: (317) 745-2377
www.flavorburst.com
For pricing, ordering and support,
contact one of our qualified
distributors.
This supplement is not a full operations manual. It does not contain complete
information on installing and maintaining your new system. The purpose of
this manual supplement is to provide you with additional information and
instruction, such as diagrams and part lists, which are either not included or
are different from what is shown in the standard manual. Read through these
installation and maintenance instructions first and then refer to your standard
manual for the rest of the instructions. Be sure to also refer to your standard
model to get complete information needed for your system. All manuals and
supplements are available on
©2022 Flavor Burst Company
All Rights Reserved
PLEASE READ FIRST!
www.flavorburst.com
Printed in January
Printed in
The United States of America

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CTP 80SS-DLX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Flavor Burst CTP 80SS-DLX

Summary of Contents for Flavor Burst CTP 80SS-DLX

  • Page 1 Flavor Burst ® Deluxe Cabinet - Operations Manual Supplement Models: CTP 80SS-DLX CTP 80BLD-DLX CTP 80CBB-DLX CTP 80BEV-DLX CTP 80FCB-DLX SS-DLX Manufactured by Flavor Burst Company 499 Commerce Drive Danville, IN 46122 For general information and to locate a distributor near you, call or visit our...
  • Page 2 PAGE INTENTIONALLY LEFT BLANK...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS FCC Conformity Statement..…...………………………………………….………………...3 Introduction……………………………...………………………………………….………….4 Safety Precautions……………………………..…………….………..……..….…………..4 Environmental Notices………………...………………………………………….………….5 Parts Identification/Function……...……………………….……..…..……….……..….…..7 Equipment ........…………………………………………..….……..….46 Connecting the Unit Syrup Line and Pump Harness Cable…….………...…..… 46 Installing the Electronics Box and Power Connections……………….…….……..48 Filling the Sanitizer Tank………………………………………….……………..….50 EQUIPMENT SETUP - Continued……………………………….……………..….52 Other Important Information.…………….…….…...…………………..………..…..52 Ordering/Service Information…………….…….…...………………………...……..…..53...

  • Page 4: Fcc Conformity Statement

    FCC Conformity Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

  • Page 5: Introduction

    Consult your electrician. as it is dispensed. Dispensing Flavor Burst product is very simple. Select a flavor from the DO NOT put objects or fingers in the Touch Panel and draw the product. The Flavor door spout.

  • Page 6: Environmental Notices

    HAZARD COMMUNICATION STANDARD (HCS) – The procedure(s) in this manual NOTE: Access to the service area is restricted to persons having safety / hygiene include the use of chemical products. These knowledge and practical experience of the chemical products will be highlighted in appliance.
  • Page 7 PAGE INTENTIONALLY LEFT BLANK...

  • Page 8: Parts Identification/Function

    General Cabinet Overview (See Figure 1) ITEM PART NO. DESCRIPTION QTY. FUNCTION TOUCH PANEL ASSEMBLY ELE 906A Flavor Burst unit command center. WITH BRACKET ELE 434 POWER CABLE Supplies the electronics board with power. FOR “SS” SYSTEMS: Injects syrups into the product.
  • Page 9 General Cabinet Overview (Continued) ITEM PART NO. DESCRIPTION QTY. FUNCTION FOR “SS” “CBB” & “BLD” SYSTEMS: SYRUP BAG CONNECTOR Transports syrup from the bag to the pumps. 10-1 SYR 945 ASSEMBLY *8 for 80SS, 80BLD, 80CBB systems. **0 for 80BEV, 80FCB systems. OR…...
