1.2 DIGITILE144

DIGITILE is a LED video panel for the rental market wih 25 mm pixel pitch and an extensive range of optical
accessories for a wide variety of looks (black and white milk included, transparent on demand). Each panel
features 12x12 144 LED RGB/FC LEDs with individual pixel control, 120° viewing angle. The mechanics of
DIGITILE have been studied to grant a great mounting flexibility through a sliding hardwares on the back
for truss application and on the side for multiple vertical linking. The external control unit DIGIDRIVER is
compatible with ArtNet and KlingNet protocol, and runs both signal and power over a 4 poles cable that
provides greater stability and connection in daisy chain (up to 6 DIGITILE).
Light source and optics
• 12x12 (144 total) SMD5050 RGB/FC high-efficiency LEDs
• Luminous flux: black cover = 725 NIT, milky cover = 2900 NIT, transparent cover = 3290 NIT
• Pixel2pixel control
• Viewing angle: 120°
• Pixel pitch: 25 mm
• Color synthesis: RGB/FullColor mixing (>16 million colors)
• LEDs average life span: >50'000h
Electronics and features
• Power and signal through DIGIDRIVER (optional)
• Art-Net and Kling-Net control protocol supported
• Channels Art-Net: 432
Structure and Power supply
• Sturdy aluminum profile
117
1000
• Internal Protection: IP20
• Sliding bracket for truss rigging and vertical hardware for connection of more units
• Black matte filter (mounted), white milk filter (included), transparent filter (optional)
• Power unit: DC36V
• IN/OUT power wiring and signal through connections XLR4p (max 6 units on a DIGIDRIVER)
• Power consumption: 52,5W
• Weight: 2,6 kg
• Dimensions (WxHxD): 300x300x118 mm
117
1000
300 118
Technical drawing
