Eccentric

6. Eccentric
1. By removing individual flywheel discs
2. By turning individual flywheel discs
T01021GB.fm
All manuals and user guides at all-guides.com
The eccentric weights of these machines consist of various 1,5 mm
thick discs. These discs are fixed on the shaft (at both ends of the
shaft) and all of them are assembled either in one direction (position 1)
or at an angle of 120° one to another (position 2). Hence, the
centrifugal forces can be adjusted in several different ways.
If the maximum centrifugal force is not required, proceed according to
item 1 to obtain a low flywheel effect, and thus short starting and
slowing-down times.
20
