0109968en
006
09.2010
EXTERNAL VIBRATORS
ARFU
Operator´s Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARFU 36/6/120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wacker Neuson ARFU 36/6/120

Summary of Contents for Wacker Neuson ARFU 36/6/120

  • Page 1 0109968en 09.2010 EXTERNAL VIBRATORS ARFU Operator´s Manual...
  • Page 2 Manufacturer Wacker Neuson SE Preußenstraße 41 80809 München www.wackerneuson.com Tel.: +49-(0)89-354 02-0 Fax: +49-(0)89-354 02-390 Translation of the original operator's manual in German...

  • Page 3: Table Of Contents

    Inhalt Foreword ........................4 Safety ......................... 5 2.1 Principle......................5 2.2 Qualification of the operating personnel ............. 8 2.3 Protective gear ....................9 2.4 Transport ......................10 2.5 Operating safety ....................10 2.6 Safety during the operation of electric appliances..........12 2.7 Safety during the operation of external vibrators..........

  • Page 4: Foreword

    Foreword This operator's manual contains information and procedures for the safe opera- tion and maintenance of your Wacker Neuson machine. In the interest of your own safety and to prevent accidents, you should carefully read through the safety information, familiarize yourself with it and observe it at all times.

  • Page 5: Safety

    In particular, the machine may not be used for the following purposes: Immersion in fresh concrete. Other special applications must be checked and released by Wacker Neuson. Its proper use also includes the observance of all instructions contained in this operator's manual as well as complying with the required service and mainte- nance instructions.
  • Page 6 Installation of accessories which are not from Wacker Neuson. It is no problem to install spare parts from Wacker Neuson. It is no problem to install accessories that are available in the Wacker Neuson product range of your machine. Please refer to the installation regulations in this operator's manual.
  • Page 7 Have damaged or defective components replaced immediately! For further information, refer to chapter Troubleshooting. Spare parts, accessories Use only spare parts from Wacker Neuson or such that are equivalent to the orig- inal parts in design and quality. Only use accessories from Wacker Neuson.

  • Page 8: Qualification Of The Operating Personnel

    2 Safety Country-specific regulations Observe the country-specific regulations, standards and guidelines in reference to accident prevention and environmental safety, for example those pertaining to hazardous materials and wearing protective gear. Complement the operator's manual with additional instructions taking into ac- count the operational, regulatory, national or generally applicable safety guide- lines.

  • Page 9: Protective Gear

    You can find the exact value in the chapter Technical Data. When wearing ear protection while working, you must pay attention and exercise caution because your hearing is limited, e.g. in case someone screams or a sig- nal tone sounds. Wacker Neuson recommends that you always wear ear protection.

  • Page 10: Transport

    2 Safety Transport Switching off the machine Before you transport the machine, switch it off and pull the plug out of the plug receptacle. Allow the motor to cool down. Transporting the machine Secure the machine on the transport device against tilting, falling or slipping. Lifting the machine A falling machine can cause serious injuries.
  • Page 11 2 Safety Starting the machine Observe the safety information and warning notices located on the machine and in the operator's manual. Never attempt to start a machine that requires maintenance or repairs. Start the machine as described in the operator's manual. Avoid body contact with grounded components.

  • Page 12: Safety During The Operation Of Electric Appliances

    2 Safety Safety during the operation of electric appliances Specific regulations for electrical appliances Observe the safety information provided in the brochure General Safety Rules which is included in the scope of delivery of your machine. Also observe the country-specific regulations, standards and guidelines in refer- ence to accident prevention in connection with electrical equipment and ma- chines.
  • Page 13 I, see chapter Technical data). Only use tested extension cables which are suitable for use at construction sites: Average rubber hose H05RN-F or better – Wacker Neuson recommends H07RN-F, an SOW cable, or a country-specific equivalent design. Immediately replace damaged extension cables (e.g. tears in the sheathing) or loose plugs and couplings.

  • Page 14: Safety During The Operation Of External Vibrators

    Sufficient stability for the used external vibrator type (dependent on the performance). Your Wacker Neuson representative will be happy to assist you. Using the correct fastening clamp Attach the external vibrator using the fastening clamp which is suitable for the external vibrator and the formwork.
  • Page 15 2 Safety Cleaning Always keep the machine clean and be sure to clean it each time you have fin- ished using it. Do not use gasoline or solvents. Danger of explosion! Do not use high pressure washers. Permeating water can damage the machine. When electrical equipment is present, this can pose a serious injury risk from electric shocks.

  • Page 16: Safety And Information Labels

    3 Safety and information labels Safety and information labels Your machine has adhesive labels containing the most important instructions and safety information. Make sure that all the labels are kept legible. Replace any missing or illegible labels. The item numbers for the labels are in the parts book. Item Label Description...

  • Page 17: Scope Of Delivery

    Scope of delivery Scope of delivery The scope of delivery includes: Machine. Operator's manual. Parts book. General safety instructions.

  • Page 18: Description

    Description Description Operating range To be used in pre-cast concrete factories for the vibration of forms of all kinds as well as for installation on vibrating tables, vibrating blocks, and machines. In building construction and civil engineering to be used as form vibrators in all pre-cast concrete factories to fit planks, plates, etc.

  • Page 19: Connection

    Description Connection Prior to connection please check: The voltage used has to correspond to the data shown on the rating plate. The equipment must be connected to an appropriate electric power system. Assembly instructions for the version without plug receptacle Danger of electrocution! Only a qualified electrician is permitted to assemble the plug and perform a safety check according to the directives in effect.

  • Page 20: Maintenance

    Maintenance Maintenance Maintenance schedule Maintenance Parts Maintenance jobs intervals Check for perfect condition Supply cable (11) daily - replace defective cable. Tighten all accessible screw External vibrator (1) after first 20 hours connections.

  • Page 21: Troubleshooting

    Power cable is interrupted. Check power cable, have it re- placed if defective. * Bearing defective. Have the machine repaired. * * Have these tasks carried out by the service department of your Wacker Neuson representative per- son. ® Bodyguard Malfunction...

  • Page 22: Inverter

    2. Eliminate the fault or have it eliminated. * 3. Insert the plug. ® No Bodyguard present. Have the machine repaired. * * Have these tasks carried out by the service department of your Wacker Neuson representative per- son.

  • Page 23: Eccentric

    Eccentric Eccentric ARFU 36/6/... Flywheel No. 0127791 Quantity per machine Standard Quantity per machine max. External diameter (D) Thickness = 1,5 Borehole diameter (d) = 14 The eccentric weights of these machines consist of various 1,5 mm thick discs. These discs are fixed on the shaft (at both ends of the shaft) and all of them are assembled either in one direction (position 1) or at an angle of 120°...
  • Page 24 Eccentric Number of Number of eccentric weights eccentric weights Centrifugal Moment of inertia side Pos 1 side Pos 2 0,43 0,53 0,87 1,05 1,30 1,58 1,74 2,11 2,17 2,63 2,60 3,16 3,04 3,69 3,47 4,21 2,85 2,30 1,89 1,74 2,42 1,89 1,56 1,99...

  • Page 25: Disposal

    9 Disposal Disposal Disposal of waste electrical and electronic equipment For customers in EU countries This device is subject to the European Directive 2002/96/EC on waste electrical and electronic equipment (WEEE) and the corresponding national legislation. The WEEE directive outlines the procedure for handling electrical waste equip- ment across the EU.

  • Page 26: 10 Technical Data

    Technical data 10 Technical data 10.1 Machine Designation Unit ARFU 36/6/230 ARFU 36/6/120 Item no. 0610000 0610002 0610003 Length x Width x Height 232 x 227 x 102,5 (in) (9.1 x 8.9 x 4.0) Weight (withoul Converter) kg (lb) 5,8 (12.79)

  • Page 27: Converter

    Technical data 10.2 Converter Designation Unit ARFU 36/6/230 ARFU 36/6/120 Item no. 0610000 0610002 0610003 Alternating current 220 - 240 1~ 110 - 130 1~ Frequency 50/60 Power input 1,38 Rated current Status LED ON/OFF switch...

  • Page 28: Extension Cable

    Technical data 10.3 Extension cable WARNING Electrical voltage. Injuries from electrocution. Check power cable and extension cable for signs of damage. Only use extension cables for which grounded conductors are connected to the plug and the coupling (only for machines of class rating I, see chapter Technical Data).
  • Page 29 Technical data Extension cable for the US market: Machine Voltage Extension Cross-section [ft] area of cable [AWG] ARFU 36 120 1~ < 59 < 93 < 148...

  • Page 30: 11 Glossary

    11 Glossary 11 Glossary Class rating The class rating according to DIN EN 61140 specifies the safety measures for electrical equipment to avoid electrocution. There are four class ratings: Class rating Meaning No special protection apart from the basic insulation. No grounded conductor.
  • Page 31 11 Glossary Protection class IP The protection class according to DIN EN 60529 indicates the suitability of elec- trical equipment for use in certain ambient conditions as well as the protection against risks. The protection class is specified by an IP code according to DIN EN 60529. Code Meaning 1st number: Protection against touching hazardous parts.
  • Page 32 11 Glossary...

  • Page 33: Declaration Of Incorporation

    Declaration of incorporation Manufacturer Wacker Neuson SE Preußenstraße 41 80809 München Product Type ARFU 36 Product type External vibrator Item no. 0610000, 0610002, 0610003 Declaration of incorporation We hereby declare that this product is designed for installation in a machine and that com-...
