Chapter 2: System Requirement and Installation

System Requirement

To access the Wireless IAD via Ethernet, the host computer must meet the following
requirements:
Equipped with an Ethernet network interface.
Have TCP/IP installed.
Allow the client PC to obtain an IP address automatically or set
a fixed IP address.
With a web browser installed: Internet Explorer 5.x or later.
The Wireless IAD is configured with the default IP address of 192.168.1.1 and
subnet mask of 255.255.255.0. Considering that the DHCP server is enabled by
default, the DHCP clients should be able to access the Wireless IAD, or the host PC
should be assigned an IP address first for initial configuration.
You also can manage the Wireless IAD through a web browser-based manager:
ADSL ROUTER CONTROL PANEL. The Wireless IAD manager uses the HTTP
protocol via a web browser to allow you to set up and manage the device.
To configure the device via web browser, at least one
properly-configured PC must be connected to the network (either
connected directly or through an external hub/switch to the LAN port of
the device).

Choosing a place for the Wireless IAD

Place the Wireless IAD close to ADSL wall outlet and power outlet for the
cable to reach it easily.
Avoid placing the device in places where people may walk on the cables. Also
keep it away from direct sunlight or heat sources.
Place the device on a flat and stable stand.
Chapter 2: System Requirement and Installation
3
