Appendix A: Specifications - Dynalink ADSL2+ Wireless VoIP Router RTA1046VW User Manual

Interface
Regulatory Approvals
and Compliance
Power Requirement
and Operation
Environment
Requirement
Physical
148

Appendix A: Specifications

One RJ-11 port for ADSL connection
One RJ-11 port (FXO port) for connecting to PSTN line
Two RJ-11 ports (FXS ports) for VoIP phone calls
Four RJ-45 ports for IEEE 802.3/802.3u 10/100 Base-T
auto-sensing and auto-crossover Ethernet connection
One USB client port compliant to USB 1.1
Hidden mini-PCI interface for IEEE 802.11g (2.4 GHz)
wireless LAN connection
One hidden button for restoration of factory default
settings
EMC: FCC part 15 Class B, CE
Telecom: FCC part 68
Safety: UL, CB, LVD
Power Adaptor:
Power Consumption:
Ambient Temperature:
Relative Humidity:
PCB: 192 mm x 138 mm
Housing: 220 mm (L) x 155 mm (W) x 40 mm (H)
Weight: 528g
Appendix A: Specifications
Input 120±10 or 230±10 VAC;
Output 12 VAC, 1.5A
less than 15 Watt
0 to 40°C (32 to 96°F)
20% to 90% (non-condensing)
