Dynalink RTA1320 User Manual

Adsl2+ modem router
Hide thumbs Also See for RTA1320:
Table of Contents

Advertisement

Quick Links

User Manual

RTA1320

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RTA1320 and is the answer not in the manual?

Questions and answers

Related Manuals for Dynalink RTA1320

Summary of Contents for Dynalink RTA1320

  • Page 1: User Manual

    User Manual RTA1320...
  • Page 2 ADSL Router User Manual © 2005 All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of the seller. Information in this document is subject to change without notice.
  • Page 3 For Installation Use only the type of power source indicated on the marking labels. Use only power adapter supplied with the product. Do not overload wall outlet or extension cords as this may increase the risk of electric shock or fire. If the power cord is frayed, replace it with a new one.
  • Page 4 ADSL Router User Manual This equipment must be installed and operated in accordance with provided instructions and a minimum 20 cm spacing must be provided between computer mounted antenna and person’s body (excluding extremities of hands, wrist and feet) during wireless modes of operation. This device complies with Part 15 of the FCC Rules.

  • Page 5: Table Of Contents

    Contents Before You Use... IX Unpacking ...IX Features ...IX ADSL Compliance ...IX ADSL2 Compliance ...IX ADSL2+ Compliance...IX ATM Features ... X Bridging Features... X Routing Features ... X Security Features... X Configuration and Management ...XI Subscription for ADSL Service ...XI Chapter 1: Overview ...
  • Page 6 ADSL Router User Manual Bridge Mode ... 64 MER... 65 Chapter 4: Web Configuration ... 67 Using Web-Based Manager ... 67 Outline of Web Manager... 68 To Have the New Settings Take Effect ... 68 Language ... 68 Quick Start ... 69 Connect to Internet ...
  • Page 7 Chapter 5: Troubleshooting ... 121 Problems with LAN ... 121 Problems with WAN ... 121 Problems with Upgrading ... 122 Chapter 6: Glossary ... 123 Appendix: Specifications ... 125 Contents...
  • Page 8 ADSL Router User Manual VIII...

  • Page 9: Before You Use

    ADSL allows you to have both voice and data services in use simultaneously all over one phone line. RTA1320 ADSL2+ Router is a low-cost DSL broadband access device for home or office users. It supports ADSL2/ADSL2+ and is backward compatible to ADSL, even offers auto-negotiation capability for different flavors (G.dmt, G.lite, or T1.413 Issue 2)

  • Page 10: Atm Features

    ADSL Router User Manual ATM Features Compliant to ATM Forum UNI 3.1 / 4.0 Permanent Virtual Circuits (PVCs) Support up to 8 PVCs for UBR, CBR, VBR-nrt, VBR-rt with traffic shaping RFC2684 LLC Encapsulation and VC Multiplexing over AAL5 RFC2364 Point-to-Point Protocol (PPP) over AAL5 RFC2225 Classical IP and ARP over ATM RFC2516 PPP over Ethernet: support Relay (Transparent Forwarding) and Client functions...

  • Page 11: Configuration And Management

    etc) Configuration and Management User-friendly embedded web configuration interface with password protection Remote management accesses control Telnet session for local or remote management Firmware upgrades through HTTP or TFTP The boot loader contains very simple web page to allow the users to update the run-time firmware image.
  • Page 12 ADSL Router User Manual Notes and Cautions Note and Caution in this manual are highlighted with graphics as below to indicate important information. Note Caution Contains information that corresponds to a specific topic. Represents essential steps, actions, or messages that should not be ignored.

  • Page 13: Chapter 1: Overview

    Chapter 1: Overview This chapter provides you the description for the LEDs and connectors on the front and rear surface of the router. Before you use/install this router, please take a look at this information first. Physical Outlook Front Panel The following illustration shows the front panel of the ADSL Router: LED Indicators The ADSL Router is equipped with several LEDs on the front panel as described in...

  • Page 14: Rear Panel

    ADSL Router User Manual Rear Panel The following figure illustrates the rear panel of your ADSL Router: Connector Ethernet 9VAC Description RJ-11 connector USB connector Ethernet RJ-45 connector Power switch 9VAC Power connector Note: For use only with power supply HON-KWANG type A9100-230, Leader type A41090100.

  • Page 15: Chapter 2: System Requirement And Installation

    Chapter 2: System Requirement and Installation Chapter 2: System Requirement and Installation System Requirement To access the ADSL Router via Ethernet, the host computer must meet the following requirements: Equipped with an Ethernet network interface. Have TCP/IP installed. Allow the client PC to obtain an IP address automatically or set a fixed IP address.

  • Page 16: Connecting The Adsl Router

    ADSL Router User Manual Connecting the ADSL Router Follow the steps below to connect the related devices. Use a RJ-11 cable (standard telephone cord) to connect the DSL port of the router to the DSL wall outlet. Please attach one end of the Ethernet cable with RJ-45 connector to the LAN port of your ADSL...

  • Page 17: Usb Driver Installation

    Chapter 2: System Requirement and Installation When connecting through a hub, please refer to the following diagram for illustration. USB Driver Installation If the ADSL router is connected to a PC through the USB interface, you will be prompted for the USB drivers when plugging the USB cable to the PC. Refer to the relevant operating system to install the USB drivers.
  • Page 18 ADSL Router User Manual An InstallShield Wizard will appear. Please wait for a moment. When the welcome screen appears, click Next for the next step. When the complete window of the InstallShield Wizard appears, click Finish. Link your router and the PC with a USB cable. The system will detect the USB driver automatically.
  • Page 19 Chapter 2: System Requirement and Installation When the file copying finished, the dialog above will close. Now the USB driver is installed properly. You can use the router. To make sure that your router is properly installed, please do the following steps. 1.

  • Page 20: For Windows Xp

    ADSL Router User Manual For Windows XP Run the USB installation program from the CD provided in your router package. An InstallShield Wizard will appear. Please wait for a moment. When the welcome screen appears, click Next for the next step. When the complete message of InstallShield Wizard appears, click Finish.
  • Page 21 Chapter 2: System Requirement and Installation Then the system will try to find the proper driver for your router and copy the files automatically. After the file copying finished, a completing message will appear. You can use the router now. To make sure your router is properly installed, please do the following steps.
  • Page 22 ADSL Router User Manual 3. Confirm that the Askey ADSL Router USB Remote NDIS Device is on the Network adapters list.

  • Page 23: For Windows Vista

    Chapter 2: System Requirement and Installation For Windows Vista For Vista users, please press Continue whenever a prompted window asking for permission to continue during USB driver installation process (see the figure below for example). To install the USB driver before connect the router to the PC, here provides two methods.
  • Page 24 ADSL Router User Manual When the complete message of InstallShield Wizard appears, click Finish. Link your router and the PC with a USB cable. The system will detect the USB driver automatically. Note: If the USB device is not detected, check the USB cable between the PC and the device.
  • Page 25 Chapter 2: System Requirement and Installation Method Two – Run a silent installation. Copy the USB driver folder from the driver CD to somewhere on the PC. (In our example, the driver files are put under D:\Askey ADSL USB WHQLed.) Open Start menu, key in cmd in the blank and press enter.
  • Page 26 ADSL Router User Manual If the USB driver has not been installed yet, you can also connect the router to the PC with a USB cable and wait for Universal Plug and Play device to detect the router, and then install the driver. Plug the USB cable into the USB port on the PC.
  • Page 27 Chapter 2: System Requirement and Installation Or if you do not have a disc, but have the driver files on your PC, you can follow the steps below: Press I don’t have the disc. Show me other options. Select Browse my computer for driver software (advanced). Press Browse to set the path for the driver file, and then press Next.
  • Page 28 ADSL Router User Manual Wait while the system installing the driver. Now the driver software is installed successfully. Press Close to start using the router. To make sure the USB driver for your router is properly installed, please do the following steps.
  • Page 29 Chapter 2: System Requirement and Installation 2. On the Control Panel folder, click System and Maintenance. 3. Press System. 4. Click Device Manager.
  • Page 30 ADSL Router User Manual 5. Confirm that the Askey ADSL Router USB Remote NDIS Device is on the Network adapters list.

  • Page 31: Uninstalling The Usb Driver

    Chapter 2: System Requirement and Installation Uninstalling the USB Driver For Windows ME To uninstall the USB driver, please follow the procedures below. Method One: Unplug the USB cable from the USB port on your PC. Choose Programs – Askey Broadband – Uninstall Askey ADSL Router USB Driver from the Start menu.
  • Page 32 ADSL Router User Manual Choose Programs – Askey Broadband – Uninstall Askey ADSL Router USB Driver from the Start menu. The InstallShield Wizard dialog will appear. A dialog appears to confirm whether you want to remove the USB driver or not.
  • Page 33 Chapter 2: System Requirement and Installation Method Two: To safely unplug the USB cable from the USB port on your PC: Go to the right lower corner for Unplug and Eject Hardware and left click on it. Click the dialog for Stop Askey ADSL Router USB Remote NDIS Device.
  • Page 34 ADSL Router User Manual A Confirm Uninstall dialog will show up, unplug your device from the USB port and click OK. The InstallShield Wizard will guide you till the USB driver is removed. When the Maintenance Complete screen appears, the USB driver is removed successfully.

  • Page 35: For Windows Xp

    Chapter 2: System Requirement and Installation For Windows XP To uninstall the USB driver, there are two ways to do it. Please do as follows. Method One: Unplug your USB cable between your router and your PC. Choose Programs – Askey Broadband – Uninstall Askey ADSL Router USB Driver from the Start menu.
  • Page 36 ADSL Router User Manual Choose Settings – Control Panel from the Start menu. Choose Add or Remove Programs. A dialog appears to ask you to choose the program that you want to remove. Please select Askey ADSL Router USB Driver and click Change/Remove. The InstallShield Wizard dialog will appear.

  • Page 37: For Windows Vista

    Chapter 2: System Requirement and Installation For Windows Vista For Vista users, please press Continue whenever a prompted window asking for permission to continue during USB driver uninstallation process (see the figure below for example). To uninstall the USB driver, there are two ways to do it. Please follow the instructions.
  • Page 38 ADSL Router User Manual Press System. Click Device Manager. Right click Askey ADSL Router USB Remote NDIS Device on the Network adapters list, and press Uninstall.
  • Page 39 Chapter 2: System Requirement and Installation Click OK when the Confirm Uninstall window appears. Remember to unplug the USB cable before continue the uninstallation, or you will see the reminder as follows. Unplug and press OK. When the Confirm Device Uninstall screen show up, check Delete the driver software for the device and click OK to continue.
  • Page 40 ADSL Router User Manual Method Two – uninstall from program list Note: If your USB driver is installed by UPnP device, you can only use method one (via the Device Manager) to uninstall, because the installed driver will not be shown on the program list.
  • Page 41 Chapter 2: System Requirement and Installation When Maintenance Complete window shows up, click Finish to exit. The USB driver is successfully removed now.

  • Page 42: Setting Up Tcp/Ip

    ADSL Router User Manual Setting up TCP/IP If the TCP/IP protocol has not been installed yet, please follow the steps below for installation. In the following illustrations, we will set the PC to get an IP address automatically at the same time. For Windows 98 Open the Start menu, point to Settings and...
  • Page 43 Chapter 2: System Requirement and Installation The Network window appears. On the Configuration tab, check out the list of installed network components. Option 1: If there is no TCP/IP protocol, click Add. Option 2: If you have TCP/IP protocol, skip to Step 6. Your networ interface card.
  • Page 44 ADSL Router User Manual On the IP Address tab: Enable Obtain an IP address automatically and click OK. When returning to the Network window, click OK Wait for Windows when copying files. 10. When prompted with System Settings Change dialog box, click Yes to restart your computer.

  • Page 45: For Windows Me

    Chapter 2: System Requirement and Installation For Windows ME 1. Open the Start menu, point to Settings and click on Control Panel. 2. Double-click the Network icon. 3. The Network window appears. On the Configuration tab, check out the list of installed network components.
  • Page 46 ADSL Router User Manual 5. Highlight Microsoft on the left side of the windows, and select TCP/IP on the right side. Then click OK. 6. While returning to Network window, highlight TCP/IP protocol for your NIC and click Properties. 7. On IP Address tab: Enable Obtain an IP address automatically and click OK.

  • Page 47: For Windows Nt

    Chapter 2: System Requirement and Installation 8. While returning to the Network window, click OK. 9. Wait for Windows when copying files. 10. When prompted with the System Settings Change dialog box, click Yes to restart your computer. For Windows NT 1.
  • Page 48 ADSL Router User Manual 3. The Network window appears. On the Protocols tab, check out the list of installed network components. Option 1: If there is no TCP/IP Protocol, click Add. Option 2: If you have TCP/IP Protocol installed, skip to Step 7. 4.
  • Page 49 Chapter 2: System Requirement and Installation 6. When returning to the Network window. Open the Protocols tab, then select TCP/IP Protocol and click Properties. Enable Obtain an IP address from a DHCP server and click When prompted with the message below, click Yes to continue.

  • Page 50: For Windows 2000

    ADSL Router User Manual When returning to Network window, click Close. 10. When prompted with Network Settings Change dialog box, click Yes to restart your computer. For Windows 2000 From the Start menu, point to Settings and then click Network and Dial-up Connections.
  • Page 51 Chapter 2: System Requirement and Installation Right-click the Local Area Connection icon and then click Properties. On the General tab, check out the list of installed network components. Option 1: If there is no TCP/IP Protocol, click Install. Option 2: If you have TCP/IP Protocol, skip to Step 6.
  • Page 52 ADSL Router User Manual Click Internet Protocol (TCP/IP) and then click OK. When returning to the Local Area Connection Properties window, highlight Internet Protocol (TCP/IP) and then click Properties. Under the General tab, enable Obtain an IP address automatically. Then click OK.

  • Page 53: For Windows Xp

    Chapter 2: System Requirement and Installation For Windows XP Open the Start menu, point to Control Panel and click it. Double click the Network Connection. Right click Local Area Connection and then click Properties.
  • Page 54 ADSL Router User Manual On the General tab, check out the list of installed network components. Option 1: If there is no TCP/IP Protocol, click Install. Option 2: If you have TCP/IP Protocol, skip to Step 7. If there is no TCP/IP protocol installed on your PC, press Install to continue.
  • Page 55 Chapter 2: System Requirement and Installation When it returns to the General Tab on the Local Area Connection Properties window, highlight Internet Protocol (TCP/IP) and then click Properties. Under the General tab, select Obtain an IP address automatically, and Obtain DNS server address automatically.

  • Page 56: For Windows Vista

    ADSL Router User Manual For Windows Vista Open the Start menu, point to Control Panel and click it. Click Network and Internet. Select Network and Sharing Center.
  • Page 57 Chapter 2: System Requirement and Installation Click Manage Network Connection on the left side. Right click Local Area Connection and select Properties. On the Networking tab, you will find Internet Protocol Version 6 and Version 4. Contact your ISP to confirm which one will be used.
  • Page 58 ADSL Router User Manual Under the General tab, select Obtain an IP address automatically, and Obtain DNS server address automatically. Then click Ok to exit.

  • Page 59: Renewing Ip Address On Client Pc

    Chapter 2: System Requirement and Installation Renewing IP Address on Client PC After the ADSL Router gets on line, there is a chance that your PC does not renew its IP address and thus causes the PC not able to access the Internet. To solve this problem, please follow the procedures below to renew PC’s IP address.
  • Page 60 ADSL Router User Manual 2. Type cmd in the text box that appears and click OK. Then you will see the command prompt window. Another way to open the command prompt: From Start menu, point to Programs, select Accessories, and then click Command Prompt. 3.

  • Page 61: For Windows Vista

    Chapter 2: System Requirement and Installation For Windows Vista 1. Open the Start menu, and type cmd in the text box then click OK. 2. The command prompt window will appear. 3. Type ipconfig at the command window and press Enter to view the computer’s IP information from DHCP server.
  • Page 62 ADSL Router User Manual Note: If you cannot release the IP address successfully and see the message “The requested operation requires elevation,” please go to the Start menu and right click Command Prompt, then set Run as administrator. Press Continue when a dialog asking for permission to continue prompts.

  • Page 63: Chapter 3: Accessing The Internet

    Chapter 3: Accessing the Internet This chapter aims to help you access the Internet in a quick and convenient way. If you need more detailed information for web configuration, please refer to the next chapter for the advanced configuration. Before configuring the ADSL Router, you must decide whether to configure the ADSL Router as a bridge or as a router.

  • Page 64: Ppp Over Atm (Pppoa) Mode

    ADSL Router User Manual PPP over ATM (PPPoA) Mode (Internet Service Provider) RDAIUS Server *BRAS: Broadband Remote Access Server Description: In this deployment environment, the PPPoA session is between the ADSL WAN interface and BRAS. The ADSL Router gets a public IP address from BRAS when connecting to DSLAM.

  • Page 65: Ppp Over Atm (Pppoa) Ip Extension Mode

    PPP over ATM (PPPoA) IP Extension Mode STM-1 (Internet Service Provider) BRAS RDAIUS Server PPP over ATM *BRAS: Broadband Remote Access Server Description: In this deployment environment, the PPPoA session is between the ADSL WAN interface and BRAS. The ADSL Router acts as a bridge and receives a public IP address from BRAS for your computer.

  • Page 66: Ppp Over Ethernet (Pppoe) Mode

    ADSL Router User Manual PPP over Ethernet (PPPoE) Mode (Internet Service Provider) RDAIUS Server *BRAS: Broadband Remote Access Server Description: In this deployment environment, the PPPoE session is between the ADSL WAN interface and BRAS. The ADSL Router gets a public IP address from BRAS when connecting to DSLAM.

  • Page 67: Ppp Over Ethernet (Pppoe) Ip Extension Mode

    PPP over Ethernet (PPPoE) IP Extension Mode (Internet Service Provider) STM-1 BRAS RDAIUS Server PPP over Ethernet *BRAS: Broadband Remote Access Server Extension Mode Description: In this deployment environment, the PPPoE session is between the ADSL WAN interface and BRAS. The ADSL Router acts as a bridge and gets a public IP address from BRAS for your computer.

  • Page 68: Numbered Ip Over Atm (Ipoa)

    ADSL Router User Manual Numbered IP over ATM (IPoA) (Internet Service Provider) RDAIUS Server *BRAS: Broadband Remote Access Server Description: If you apply for multiple IP addresses from your ISP, you can assign these public IP addresses to the ADSL Router and public server, e.g., Web or FTP server. Typically the first IP is network address, the second is used as router IP address and the last one is for subnet broadcasting.
  • Page 69 Subnet mask: 255.255.255.248 Click Next. Check the network information on the Summary page. Make sure the settings match the settings provided by your ISP. Click Finish. Refer to the TCP/IP properties, specify an IP Address, and fill in other information needed, e.g.: IP Address: 10.11.80.82 Subnet Mask: 255.255.255.248 Gateway: 10.11.80.81...

  • Page 70: Numbered Ip Over Atm (Ipoa)+Nat

    ADSL Router User Manual Numbered IP over ATM (IPoA)+NAT Description: In this deployment environment, we make up a private IP network of 192.168.1.1. NAT function is enabled (on ADSL Router or use another NAT box connected to hub) to support multiple clients to access the Router and some public servers (WWW, FTP).
  • Page 71 On the Configure LAN side Settings page, key in the information for your LAN, e.g., Primary IP Address: 192.168.1.1 Subnet mask: 255.255.255.0 Start IP Address: 192.168.1.2 End IP Address: 192.168.1.254 Check the network information. Make sure the settings match the settings provided by ISP.

  • Page 72: Unnumbered Ip Over Atm (Ipoa)

    ADSL Router User Manual Unnumbered IP over ATM (IPoA) (Internet Service Provider) RDAIUS Server *BRAS: Broadband Remote Access Server Description: If you apply for multiple IP addresses from your ISP, you can assign these public IP addresses to the ADSL Router and public server, e.g., Web or FTP server. Typically the first IP is network address, the second is used as router IP address and the last one is subnet broadcasting.
  • Page 73 Check the network information on the Summary page. Make sure the settings match the settings provided by your ISP. Click Finish. Refer to the TCP/IP properties, specify an IP Address, and fill in other information needed, e.g.: IP Address: 10.11.80.82 Subnet Mask: 255.255.255.248 Gateway: 10.11.80.81 Preferred DNS server: 168.95.1.1...

  • Page 74: Unnumbered Ip Over Atm (Ipoa)+Nat

    ADSL Router User Manual Unnumbered IP over ATM (IPoA)+NAT Description: If you apply for multiple IP addresses from your ISP, you can assign these public IP addresses to the ADSL Router and public server, e.g., Web or FTP server. Typically the first IP is network address, the second is used as router IP address and the last one is subnet broadcasting.
  • Page 75 Check Configure the second IP Address and Subnet Mask for LAN Interface and enter the information needed, e.g., Secondary IP Address: 10.11.80.81 Subnet mask: 255.255.255.248 Click Next. Check the network information on the Summary page. Make sure the contents match the settings provided by your ISP. Click Finish. Now the router is well-configured.

  • Page 76: Bridge Mode

    ADSL Router User Manual Bridge Mode (Internet Service Provider) RDAIUS Server *BRAS: Broadband Remote Access Server Description: In this example, the ADSL Router acts as a bridge which bridging the PC IP addresses from LAN to WAN. The PC IP address can be a static public address that is pre-assigned by the ISP or a dynamic public address that is assigned by the ISP DHCP server, or an IP address received from PPPoE software.

  • Page 77: Mer

    STM-1 (Internet Service Provider) BRAS RDAIUS Server *BRAS: Broadband Remote Access Server Description: In this deployment environment, we make up a private IP network of 192.168.1.1. NAT function is enabled to support multiple clients to access to Internet. In this example, the ADSL Router acts as a NAT device which translates a private IP address into a public address.
  • Page 78 ADSL Router User Manual...

  • Page 79: Chapter 4: Web Configuration

    Chapter 4: Web Configuration Some users might want to set specific configuration for the router such as firewall, data transmission rate…, and so on. This chapter will provide you advanced information of the web pages for the router for your reference. Using Web-Based Manager After properly configuring your host PC, please proceed as follows: Chapter 4: Web Configuration...

  • Page 80: Outline Of Web Manager

    ADSL Router User Manual Outlin e of Web Manager To configu re the web page, please use admin as the userna The main screen will be shown as below. Title Title: Main Menu: Main Window: Current Version: To Have the New Settings Take Effect After selecting or adjusting the settings according to your needs, your customizations will be saved to the flash memory before you restart the router.

  • Page 81: Quick Start

    Quick Start The pages under the Quick Start menu provide user a quick way to set up the router. If you do not know much about the router, you can use the Quick Start pages to adjust basic settings to activate your router. Connect to Internet This is a quick way to connect to the Internet by using PPPoE interface,...

  • Page 82: Connection Type

    ADSL Router User Manual Connection Type The system provi most suitable sett protocol that your ISP offered. After clicking on the Next button from the VPI/VCI web page, the following screen will appear. Please choose the connection type and encap mode that you want to use and click Next for next page.
  • Page 83 PPP Username & PPP Password: Key in the username and password that you received from your ISP. Always On: Select this item to make the connection active all the time. Dial on Demand: Select this item to make a connectio automatically while in demand.
  • Page 84 ADSL Router User Manual You can check the contents on the Summary page. If you find anything incorrect, click Back to modify th If everything is OK, click Finish accept these settings. Now, the system will reboot to activate the new settings that you this section.

  • Page 85: Ip Over Atm

    IP over ATM If the type you have to choose is IP information. IPoA is an alternative of LAN emulation. It allows TCP/IP network access ATM network and uses ATM uality of service’s features. hoose IPoA and click Next. None: If it is not necessary to set the WAN IP address, please click this button.
  • Page 86 ADSL Router User Manual Configure the sec Address and Sub interface: Check this bo IP Address to connect to your they are not included in the range that DHCP server accepts. You have to key in the information received from your ISP for the LAN connect the secondary IP is 10.11.80.8 the mask is 255.255.255.248 in the...

  • Page 87: Bridging

    Bridging If the mode y ou choose is Bridging (or MER), please refer to the following information. The bridging mode can configure your router to send and receive packets between LAN and WAN interfaces. The WAN interface is ATM PVC; the LAN interface can be Ethernet, USB, or Wireless.
  • Page 88 ADSL Router User Manual You can che Summary page no If you find anything incorrect, click Back to mod If everything is OK, click Finish to accept these settings. And the following page will appear. Now, the system will reboot to activate the new settin gs that you have done in this section.

  • Page 89: Status

    Chapter 4: Web Configuration Status Overview This page displays the current status for the ADSL connection, including system up time, ADSL speed, and the informati on about LAN IP address, default gateway, DNS server, firmware version, boot loader ve rsion, ADSL driver version, Ethernet MAC address, and memory size.

  • Page 90: Adsl Line

    ADSL Router User Manual ADSL Line This page shows all information for ADSL. For knowing t connection, please click ADSL BER Test button to have advanced information. Click More Information hyperlink to show more detailed information about ADSL Line Status. ADSL BER Test This test determines the quality of the ADSL connection.

  • Page 91: Internet Connection

    Chapter 4: Web Configuration Internet Connection This page displ ays the connection information for your router, such as t PVC name, VPI/VCI value, service category, protocol, invo king NAT and QoS or not, IP address, linking status and so on. Traffic Statistics This table shows the records of data going through the LAN and WAN...
  • Page 92 ADSL Router User Manual...

  • Page 93: Advanced Setup

    Chapter 4: Web Configuration Advanced Setup Local Network – IP Address This page is the same as you can see on the Configure LAN side Settings page while running the Quick Setup. It allows you to set IP Address and Subnet Mask values for LAN interface.

  • Page 94: Local Network - Dhcp Server

    ADSL Router User Manual Local Network – DHCP Server This allows you to set DHCP server on LAN interface. DHCP Server On: Check this item if DHCP service is needed on the LAN. The router will assign IP address and gat address for each of you You have to key in Start IP Address End IP Address, and Lease Time.

  • Page 95: Local Network - Upnp

    The information added will be shown on the window right away, as the right figure illustrates. That is, the specified address will be reserved and not be assigned by DHCP for oth computer(s). You may click Add button to add another set or click Close to exit Local Network –...
  • Page 96 ADSL Router User Manual forward the multicast traffic to all hosts block and interrupt the traffic of the othe multicast service, shown as the followin When IGMP snooping is invoked, it m path for multicast service to save LAN b desired, only host A and D will actually r is enabled.

  • Page 97: Internet - Connections

    Chapter 4: Web Configuration Internet – Connections To set WAN settings for each service, please open Advanced – Internet. This page allows you to edit, to remove, or to add WAN settings. If you click the Connect hyperlink under the PVC Name item, the system will connect to WAN automatically.
  • Page 98 ADSL Router User Manual After pressing Next, you will see the web page listed as the right one Choose the protocol that you would like to use. (Here is the example for choosing PPPoA.) Please refer to Quick Setup for more information if you don’t know how to set the configuration.
  • Page 99 The WAN IP settings page will differ slightly according to the protocol t you choose. The graphic is the one that you will see if you choose the PPPoE mode in the previous step. You can select Enable NAT or change the MTU value according to your needs.

  • Page 100: Internet - Dns Server

    ADSL Router User Manual Internet – DNS Server If Enable Automatic Assigned DNS the first received DNS assignment enabled PVC(s) during the connecti it is necessary for you to enter the primary and o addresses. Finish your setting and Enable Automatic Assigned DNS: Check this box to enab or uncheck this box to disable it.

  • Page 101: Internet - Adsl

    Chapter 4: Web Configuration Internet – ADSL Enable ADSL Port: Check this box to enable this function. It simply invokes the line mode that you choose here for the router. Select the support of line modes: There are several selections, and you may select them according to the line modes supported by your ISP and your needs.

  • Page 102: Ip Routing - Static Route

    ADSL Router User Manual IP Routing – Stat The table shows all static route status a A static IP routing is a manually defin route. If your local network is compo specify a routing path to the routing tabl Destination Network Address: Display the IP address that the data packets are to be sent.

  • Page 103: Ip Routing - Dynamic Routing

    Example – Static Route Here provides you an example of Static Route. For the LAN shown above, if the PC in the subnet of 192.168.1.x wants to acce the PC in the subnet of 192.168.10.x, we can set a static route in the ADSL route which the destination is the PC in the subnet 192.168.10.x and the gateway is router B.

  • Page 104: Virtual Server - Port Forwarding

    ADSL Router User Manual Virtual Server – Port Forwarding The Router implements NAT to make your entire local network appear as a single machine to the Internet. The typical situation is that you have local servers for different services and you want to make them publicly accessible. With NAT applied, it will translate the internal IP addresses of these servers to a single IP address that is unique on the Internet.
  • Page 105 IP addresses can be automatically redirected to local servers configured with private IP addresses. In other words, depending on number), the router redirects the external service request to the appropriate server (located at another internal IP address). Add New Port Forwarding To set a virtual server, please open the Virtual Server item from the Advanced setup menu.

  • Page 106: Virtual Server - Port Triggering

    ADSL Router User Manual For example, select the predefined application name Audio/Video – Media Player 7, set from ALL internet host IP addresses, and forward to 192.168.1.200. Click Apply. Be sure to reboot your router for these changes to take effect. The result will be displayed as the following figure.

  • Page 107: Virtual Server - Dmz Host

    Virtual Server – DMZ Host In computer networks, a DMZ (demilitar network inserted as a "neutral zone" be outside public network. It prevents out server that has company data. A DMZ firewall and effectively acts as a To close the function of DMZ Host, please click Discarded.

  • Page 108: Virtual Server - Static Dns

    ADSL Router User Manual Virtual Server – Static DNS This page allows you to configure DNS mapping between Domain name and IP address for your local hosts. In case you want to access the local servers with domain names from the local network, you can configure the mapping informatio on the page.

  • Page 109: Firewall - Bridge Filtering

    Firewall The firewall is a kind of software that interrupts the data between the Internet and your computer. It is the TCP/IP equivalent of a security gate at the entrance to your company. All data must pass through it, and the firewall (functions as a security guard) will allo w only authorized data to be passed into the LAN.

  • Page 110: Firewall - Ip Filtering

    ADSL Router User Manual Select traffic dir down menu, an interface which you want this rule to apply on. Then, choose a protocol and define the source or destination MAC address which you want to control. There are t ree options for traffic directio n: Outbound network to Internet;...
  • Page 111 This page provides some settings for you to adjust for adding a new outbound IP Filtering. Allow Traffic: Choose No to stop the data transmission, Yes to permit the data pass through. Protocol: Here provides several default policies for security levels for you to choose. If you don’t want to use the predefined setting, you can use User Defined to set a customized protocol according to...
  • Page 112 ADSL Router User Manual A new IP filtering setting for Outbound traffic is created in the web pag edit the setting, please into the editing pa setting, click another IP filtering, click Add again. To add a new Inbound IP Filtering, click Inbound traffic in the item of Select the direction to filter packets on the IP Filtering page.

  • Page 113: Quality Of Service

    Quality of Service QoS (Quality of Service) is an industr treatment to certain subsets of data, e intranet with higher quality transmiss There have been two generations of q The interpretation of the Type of Service Octet in the Internet Protocol header varies between these two generations.

  • Page 114: Quality Of Service - Bridge Qos

    ADSL Router User Manual Quality of Service – Bridge QoS To classify the upstream traffic by assigning the transmission priority for different users’ data, please use Bridge QoS to prioritize the data transmission. The Bridge QoS allows you to set settings based on layer two bridge packets.

  • Page 115: Quality Of Service - Ip Qos

    Chapter 4: Web Configuration WAN 802.1p: If 802.1p is enabled on Internet connection, WAN 802.1p value of the upstream packets can be overwritten by the selected value. You may se lect a priority from the drop-down menu. If you set the LAN 802.1p Priority 0 as the traffic condition, choose Low traffic priority for this rule, set DSCP as BE, and WAN 802.1p as no...
  • Page 116 ADSL Router User Manual Source IP/ Sub Key in the source IP address (e 192.168.1.0) and subnet mask (ex.: 255.255.255.0) for the application (ex. FTP, HTTP, and so on) that you want to invoke the QoS traffic rule. You ma simply enter the source port, ranging from 0 to 65535, as the traffic condition.

  • Page 117: Port Mapping

    Chapter 4: Web Configuration Port Mapping This page allows you to configure various port mapping groups which contains specific Internet connections and LAN ports. The user data will be only transmitted and received among the interfaces in the group. Normally, this function only needed when more than two PVCs are available, for example, if we have two PVCs, one uses PPPoE and the other...
  • Page 118 ADSL Router User Manual The following relationship figure illustrates the port mapping configuration. Under this configuration, a internet through the bridge mode P will access the internet by the PPPoE c ny PC that connect to Ethernet port will connect to the VC pppoe_0_39_1, while the device using USB onnection br_0_35.

  • Page 119: Management

    Chapter 4: Web Configuration Management Diagnostics To check the linking status for the network and your computer, a diagnostic test can guide you to detect the network problem. The testing items are listed and examined one by one. If the previous one is failed, than the items following that one will be failed, too.

  • Page 120: Management Accounts

    ADSL Router User Manual Management Ac This page allows yo ADSL Router. For the Admin Account, the default setting for both username and password are admin. If you want to change the username and the password, please modify the User Name and New Passwo retype the new password in the Confirm field for confirma...

  • Page 121: Management Control - From Local

    Authorized Host IP Address List: Decide whether all internet hos access your router or only authorized internet hosts can access. Click Apply to save y our setting. Management Control – From L You can allow local access to your router via the checked interfaces. Authorized Host IP Address List: Refer to Remote Management Control.
  • Page 122 ADSL Router User Manual Connect to ACS: Choose to connect to ACS with or without SSL (Secure Socket Layer) protocol according to your ISP. If the ACS URL starts with http://, choose without SSL mode; if it begins with https://, select with SSL. ACS URL Address: Key in the Auto-Configuration Server URL Address provided by the ISP,...
  • Page 123 Press Trusted CA Ce ificates to Import Certificate obtained from you ISP, a window (as shown in the figur will be prompted for you to impor certificate. Note: The certificate may have been imported in this device already, plea check with your ISP. To synchronize your time with the server, go to Management->Internet Time to adjust the setting.

  • Page 124: Internet Time

    ADSL Router User Manual Internet Time The clock of the router must synchroniz in the screen will be adapted to sys Update Now: Click this button to refresh the current time. et Time by (Time Server/ Manual): he default setting is Manual. Select this one, and set the start time by typing the date and the time manually to help the router perform tasks.

  • Page 125: System Log

    Chapter 4: Web Configuration System Log As shown on the web page, you can view the system log and configure system log whene ver you want. To view the system log, you must config ure system log first. Press Configure System Log to start. Configuring System Log You can enable or disable the log function, and choose log level,...
  • Page 126 ADSL Router User Manual Therefore, when the log level is “Debugging” and “Error”, the CPE logs the most detailed message but shows error level data only. Mode: You can choose where to store the logs; the options include Local, Remote and Both. Local means t CPE, i.e., the ADSL Router.
  • Page 127 Viewing System Log – Remote Sid To view the system log on the Log Server (10.11.95.2), a log viewing t must be installed. 1. Down load the Kiwi Syslog Daemon from Kiwi Enterprises. Kiwi Syslog Daemon is a freeware Syslog Daemon for Windows.
  • Page 128 ADSL Router User Manual Viewing System Log – Local Side (ADSL Router) For viewing the system log on local side, click the View System Log button on the webp configuration. e system The Date/Time records the logging time, and the Facility field distinguishes different classes of system log message.

  • Page 129: Backup Config

    Chapter 4: Web Configuration Backup Config To backup your settings of the router into your computer, you can use Backup Config web page to save the settings. Click Backup button and the warning window will be prompted. Click OK to continue the backup procedure.

  • Page 130: Update Firmware

    ADSL Router User Manual After opening the ba Restore. Update Firmware If you have to or want to update the firmware for this router, you can open the Update Firmware web page and choose the correct file by pressing Browse. Then click the Update Firmware button.

  • Page 131: Upnp For Xp

    UPnP for XP Universal plug and play (UPnP) is architecture for pervasive peer to peer network connectivity of intelligent appliances and PCs of all form factors. It is designed to bring easy-to-use, flexible, standards-based connectivity to ad-hoc or unmanaged networks whether in the home, in a small business, public spaces, or attached to the Internet.
  • Page 132 ADSL Router User Manual 6. Double click on the icon, and the ADSL router wil page via the por The IE address will be directed to the management main webpage as shown in the graphic. 7. Now, the NAT traversal function has already been provided.

  • Page 133: Chapter 5: Troubleshooting

    Chapter 5: Troubleshooting the suggested solutions in this sect ystem administrator or Internet service roblems with LAN PCs on the LAN cannot get IP addresses from the ADSL Router. he chances are that the interface used as DHCP server is modified and the client Cs do not renew IP addresses.

  • Page 134: Problems With Upgrading

    ADSL Router User Manual Problems with Upgrading The following lists the error messages that you may see during upgrading and the action to take. Error message: All the ADSL LEDs light up and cannot light off as usual. Possible cause: When users are executing firmware upgrade or saving settings to the router, the power for the router the normal web page for the router might be damaged.

  • Page 135: Chapter 6: Glossary

    Chapter 6: Glossary ARP (Address R esolution Protocol ) ARP is a TCP/IP p rotocol for mapping an IP address to a physical machine address that is recognized in the local network, such as an Ethernet address. A host wishing to obtain a physical address broadcasts an ARP request onto the TCP/IP network. The host on the network that has the IP address in the request then replies with its physical hardware address.
  • Page 136 ADSL Router User Manual The ADSL Router uses private IP addresses by assigning them to the LAN that cannot be directly accessed by the Internet or r agent to translate the private Public IP Address Public IP addresses are LAN IP addresses that can be considered “legal” for the Internet, because they can be recognized and accessed by any device on the other side of the DSL connection.

  • Page 137: Appendix: Specifications

    Appendix: Specifications Interface One RJ-11 port for ADSL connection Four RJ-45 ports for IEEE 802.3/802.3u 10/100 Base auto-sensing and auto-crossover Ethernet connect One USB port compliant to USB 1.1 One hidden reset button for restoration of factory default settings Regulatory Approvals EMC: FCC part 15 Class B, CE and Compliance Telecom: FCC part 68...
