Wireless IAD User Manual

ADSL2 Compliance

ADSL2+ Compliance

Wireless LAN Compliance

x
ITU G.992.3 Annex A (G.dmt.bis)
Maximum Rate: 12 Mbps for downstream and 1 Mbps for upstream
ITU G.992.5 Annex A
Maximum Rate: 24 Mbps for downstream and 1.2 Mbps for upstream
IEEE 802.11g and IEEE 802.11b
Data Rate: 54, 48, 36, 24, 18, 12, 9, 6 Mbps for 802.11g; 11, 5.5, 2, 1 Mbps for
802.11b
Modulation Technique: OFDM for 802.11g; CCK (11 Mbps, 5.5 Mbps) for
802.11b; DQPSK (2Mbps) for 802.11b; DBPSK (1 Mbps) for 802.11b
Network Architecture: infrastructure
Operating Frequency: 2.4 ~ 2.5 GHz
Operating Channels: depending on local regulations. For example, 11
Channels (Northern America), 13 Channels (Europe), and 14 Channels (Japan)
Support the selection of best quality channel automatically
RF Transmitter:
Target Output Power (EIP):
Frequency Stability:
TX Spectrum Mask:
RF Receiver
Sensitivity: provide the implemented sensitivity and comply with
IEEE802.11b/g standard
Data Rate (Mbps)
802.11g
802.11b
Maximum input power:
Antenna: One external antenna is provided.
External Antenna: 2.4G~2.5GHz Dipole and Omni radiation antenna with 3 dBi
peak gain
Coverage Area: 300 meters
Support WEP (Wired Equivalent Privacy) mechanism which uses RC4 with
13.5 dBm (22mW) for 802.11g
17.5 dBm (56mW) for 802.11b
10 ppm
comply with IEEE802.11 b/g standard
Minimum sensitivity (dBm)
6
9
12
18
24
36
48
54
11
-10dBm
-86
-84
-82
-80
-78
-75
-70
-68
-85
