Troubleshooting

Error
Table does not
move
Table moves at a
slow rate
Hand Switch
Error Codes:
E01 - E08

Technical Data

Power supply
Maximum input current
Stand by power consumption, primarily
Operating Temperature
Height Range (Standard Range)
Height Range (Extended Stage)
Base Width
Travel Speed
Noise Level
Maximum lift capacity
(Including worksurface)
Duty Cycle
14
Solution
Ensure all cords are fully secured and the outlet your table is plugged into has
power.
Reset table.
Ensure all cables are fully secured. Follow the steps to reset your table. If you are
still encountering an error please call customer care.
Two-Column Kit, Beamless
120VAC 50/60Hz
4.2A
<0.1W
5 - 40 C
O
26.8" - 46"
21.5" - 47 .6"
Can not exceed 54" from the outside of the columns.
1" per second (no load)
<50dB
250lbs
10% Max. 2 min on, 18 mins off
