Appendix D Cable installation and power separation guidelines

For an isolated shield termination, the 1572A and 1592A outer jacket foil and drain

wire are removed a short distance back from the termination and electrical tape is used

to isolate the foil end.

Lightning protection

CommScope recommends including lightning protection in your ONECELL system

to isolate equipment from surge damage.

•

To protect the cables in an indoor installation from lightning damage, CommScope

recommends using the

NOTE

The gel filled outdoor cable types will still need blocking. See

Cable termination

D-12

Verify hole diameter – blocking may need to remain outside the cover

Maintain pair twists up to termination points

Avoid having pairs crossing over each other

ITW Linx CAT6-A-LAN

for instructions on blocking cable.

protector.

Cable splicing

M0304AG

5.5.01 April 2021

and
