CommScope ONECELL RP5200 Hardware Installation Manual page 49

•
LED Display Pattern
RADIO 1 Green, solid
RADIO 2
Amber, solid
RADIO 3
RADIO 4
Red, solid
Green, blinking
Amber, blinking
Eth 1 Green, solid
Amber, solid
Green, blinking
Amber, blinking
Red, solid
Eth 2 Green, solid
Amber, solid
Green, blinking
Amber, blinking
Red, solid
* Note: When all of the LEDs are solid red, there is an RP hardware failure.
®
ONECELL RP5200 Hardware Installation, Release 5.5
Action to take, if any, to resolve the issue
Indicates
Power On, transmitting
• RFTxState OFF
• No Controller Assigned
• No Timing
• No connection to Controller
• HW error
• Low Power
Firmware upgrade
RF module Self-Test Failure
Power On, PoE++ power
Link up, no power
PoE+ power
Platform Self-Test Failure
Ethernet port error
Power On, PoE++ power
Link up, no power
PoE+ power
Platform Self-Test Failure
Ethernet port error
Appendix B Installation troubleshooting
Action to Take
None
• Check 1588 VLAN configuration
• Verify that the Radio Point is in
STANDBY because more than 32 RPs
are connected
Hardware error – replace
None
Replace Radio Module
None
Check that the Ethernet cable is
connected to the
Radio Point
None
Replace
Radio Point
• Connect the Ethernet cable between the
Baseband Controller and Radio Point
• Replace Radio Point
None
Check that the Ethernet cable is
connected to the
Radio Point
None
Replace
Radio Point
• Connect the Ethernet cable between the
Baseband Controller and Radio Point
• Replace Radio Point
Radio Point
B-3
