Environmental And Physical Specifications - CommScope ONECELL RP5200 Hardware Installation Manual

Specifications
This appendix contains specifications for CommScope ONECELL, including FCC
information and technical data.

Environmental and physical specifications

The following table lists the electrical ratings and technical data for the RP5200.
Table C-1.
Environmental
Power Requirements
Power Consumption
Dimensions
Weight
®
ONECELL RP5200 Hardware Installation, Release 5.5
Environmental and physical specifications
SPF/SPF+ specifications
Environmental and Physical specifications
Specification Type Specification Values
Operating Temperatures: 0 to 50°C (Plenum rated: UL-2043)
Operating Humidity 10%-95% Non-Condensing
Operating temperatures: 0°C to 50°C
Active Cooling/Fans, acoustic noise: 39.5 dBA at 25C
IEEE802.3bt-type 4 PoE++
Up to: 72W (26W + 11.5W per RM)
13.54" W x13.54 H x 3.35" D
(344.0 mm W x 344.0 mm H x 85.0 mm D)
8.82 lbs (4 kg)
Appendix C
C-1
C-2
C-1
