3.3

Control panel menus

To browse menu items, turn the multi-function knob 1.
To select the highlighted menu item, press the multi-function knob 1.
• The selected active menu items are marked with a solid box.
• The Selected inactive menu items are marked with a dotted box. You cannot changed
the values of these menu items.
EN

3.3.1 MagTrac F 61 main menu

Menu item
MEMORY CH
300 mm/min
5.0 m/min
CURRENT:
VOLTAGE:
FINETUNING:
BASECURRENT:
ARC ON:
CYCLE WELD
GAS TEST
WIRE INCH
WELD DATA
SETTINGS
10
MagTrac F 61
CH OFF
MEMORY CH
300 mm/min
5.0 m/min
SET
Description
Load and save memory channels.
Change the carriage travel speed.
The selected speed is shown in the menu name.
Change the wire feed speed.
The selected speed is shown in the menu name.
Change the welding current.
The selected current is shown in the menu name.
Change the welding voltage.
The selected voltage is shown in the menu name.
Fine tune the welding values.
(Available only when using pulsed or double-pulsed welding process.)
Set the base current value.
(Available only when using WiseRoot or WiseThin welding process.)
Enable or disable the welding arc. When this function is OFF, you can test the carriage operation
without igniting the welding arc. (Note that this function is the same as pressing the ARC ON
button.)
Open the cycle weld submenu, where you can enable or disable the cycle weld function and set
its parameters.
Run the gas test.
Drive the filler wire into the gun.
Check the weld data recorded from the last welding session.
Open MagTrac F 61 settings menu.
ARC
ON
START
STOP
