- Page 1 20 , 25, 27, 32, 35, 42 Operating manual Käyttöohje Bruksanvisning Bruksanvisning Brugsanvisning Gebrauchsanweisung Gebruiksaanwijzing Manuel d’utilisation Manual de instrucciones Instrukcja obsługi Инструкции по эксплуатации 操作手册 Manual de utilização Manuale d’uso...
- Page 3 OPERATING MANUAL English...
-
Page 4: Table Of Contents
CONTENTS Introduction ......................... General . -
Page 5: Introduction
This operating manual contains important information on the use, maintenance and safety of your Kemppi product. The technical specifications of the equipment can be found at the end of the manual. Please read the operating manual and the safety instructions booklet carefully before using the equipment for the first time. -
Page 6: Operation Safety
Operation Safety Please read and follow these operational safety instructions when installing, operating and servicing the welding gun. Welding arc and welding spatter Welding arc can harm unprotected eyes. Also be aware of the risks to other people in and around the working area, as reflected arc and arc flash presents a serious risk. -
Page 7: Connecting The Gun
Check wire liner and contact tip suit the wire type and size used. For further information, please refer to section 5. Ordering numbers in this manual. Dress the sharp filler wire. Improves wire loading and consumables life. Connect the welding gun and hand tighten the collar. © Kemppi Oy / 1135... - Page 8 quick weld ARC FORCE setup data DYNAMICS GAS TEST WIRE INCH m/min / MINILOG POWER SETUP MEMORY SAVE Load filler wire using the WIRE INCH button, or use the gun trigger. WISE 1-MIG PANEL SELECT SYNERGIC PROGRAM quick weld ch clear ch remote ARC FORCE setup...
-
Page 9: Use And Maintenance
The gun is equipped at the factory with a spiral liner for welding normal steel wire. Before connecting the gun to the welding machine, make sure that the liner type meets the recommendations for the welding filler wire to be used. © Kemppi Oy / 1135... - Page 10 Components can become lose during welding heat cycles. Check regularly. Gun cable Clear dust from the liner every day during heavy use. • Clean wire liner when replacing wire reel, or more often. • Check daily that insulations of handle and gun cable are undamaged. • Check that there are no sharp bends in gun cable.
-
Page 11: Operation Disturbances
• Check filler material selection • Check filler wire delivery system • Check power supply. Are all electrical phases present? • Check that operator maintains correct technique/Arc length/travel speed/Gun angle Many of these checks may be carried out by the operator. However certain checks relating to NOTE! mains power must be completed by an authorised trained electrician. © Kemppi Oy / 1135... -
Page 12: Ordering Numbers
ORDERING NUMBERS Orange part code colour denotes standard delivery specification. NOTE! FE 20: 6602003 (3.5 m), 6602004 (5.0 m) Gas nozzle 9580101 60.5 x 18 x 14 mm, standard (A x B x C) 958010101 60.5 x 18 x 14 mm, with insulating bush (= 95801010 + 9591079) 4113470 60.5 x 18 x 14 mm, for spot welding 9580101E 60.5 x 20 x14 mm, thick wall Insulating bush 9591010 Contact tip (M6) 9876634 ø 0.6 9876635 9876633 9876636 9876637... - Page 13 Insulating ring 9591079 Locking spring 4275240 Neck 4153040 45° Wire liner 4188573 ø 0.6–0.8 mm 3.5 m W006453 0.9–1.2 mm 3.5 m W006457 0.8–1.0 mm Al/Ss 3.5 m W006459 1.0–1.6 mm Al/Ss 3.5 m 4188576 0.6–0.8 mm W006454 0.9–1.2 mm W006458 0.8–1.0 mm Al/Ss W006460 1.0–1.6 mm Al/Ss © Kemppi Oy / 1135...
- Page 14 FE 27: 6602703 (3.5 m), 6602704 (5.0 m) FE 32: 6603203 (3.5 m), 6603204 (5.0 m) Gas nozzle 4295760 76 x 20 x 14 mm, standard / M8 (A x B x C) 4295760L 79 x 20 x 14 mm, long / M8 4295760C 76 x 20 x 12 mm, conical / M8 4294970 70 x 20 x 14 mm, standard / M6 Contact tip 9876634 ø 0.6 mm (M6) 9876635 9876633 9876636 9876637 9876639 (M8) 9580122 ø 0.8 mm 9580122A ø 0.8 mm 9580121...
- Page 15 SP004585 SP600317 SP600317 50°, includes temperature protection spring as standard. Wire liner 4188573 ø 0.6–0.8 mm 3.5 m W006453 0.9–1.2 mm 3.5 m W006455 1.4–1.6 mm 3.5 m W006457 0.8–1.0 mm Al/Ss 3.5 m W006459 1.0–1.6 mm Al/Ss 3.5 m 4188576 0.6–0.8 mm W006454 0.9–1.2 mm W006456 1.4–1.6 mm W006458 0.8–1.0 mm Al/Ss W006460 1.0–1.6 mm Al/Ss © Kemppi Oy / 1135...
- Page 16 FE 42: 6604203 (3.5 m), 6604204 (5.0 m) Gas nozzle 4300380 80 x 25 x 18 mm, standard (A x B x C) 4300380L 83 x 25 x 18 mm, long 4300380C 80 x 25 x 14 mm, conical 4307070 80 x 25 x 18 mm, standard, spatter protection bush 4308190 89.5 x 25 x 18 mm, special long Insulating bush 4307030 Contact tip 9580122 ø 0.8 mm 9580122A ø 0.8 mm (M8) 9580121 9580121A 9580123 9580123A 9580124 9580124A 9580125 9580125A 9580126 9580126A 9580123ZR CuCr1Zr...
-
Page 17: Technical Data
Connection to MIG unit: Euro adapter Make sure that the gun selected is designed for the maximum welding current needed. NOTE! Kemppi welding guns meet construction and safety requirements according to the norm IEC / EN 60974-7. © Kemppi Oy / 1135... - Page 18 ул. Полковая 1, строение 6 Kotimaan myynti: 127018 Москва KEMPPI FRANCE S.A.S. Tel +358 3 899 11 Tel +7 495 739 4304 65 Avenue de la Couronne des Prés Telefax +358 3 734 8398 Telefax +7 495 739 4305 78681 EPONE CEDEX myynti.fi@kemppi.com info.ru@kemppi.com FRANCE Tel +33 1 30 90 04 40 KEMPPI SVERIGE AB KEMPPI, TRADING (BEIJING) COMPANY, Telefax +33 1 30 90 04 45 LIMITED Box 717 sales.fr@kemppi.com Room 420, 3 Zone, Building B, S-194 27 UPPLANDS VÄSBY No.12 Hongda North Street, SVERIGE KEMPPI GmbH Beijing Economic Development Zone, Tel +46 8 590 783 00 Otto-Hahn-Straße 14 100176 Beijing Telefax +46 8 590 823 94 D-35510 BUTZBACH CHINA sales.se@kemppi.com...
