8. SPECIFICATIONS

8-2. UPS with ISO transformer

MODEL
CAPACITY*
INPUT
Low line transfer
Low line comeback
Voltage
High line transfer
High line comeback
Frequency range
Phase
Power factor
OUTPUT
Output voltage
AC voltage regulation
Frequency Range
(Synchronized Range )
Frequency Range
Overload
Current crest ratio
Harmonic distortion
AC mode to batt. mode
Transfer
time
Inverter to Bypass
Waveform (Batt. mode)
23
1 kVA
FMI
1000 VA/800 W
160 VAC/140 VAC/120 VAC/110 VAC ± 5%
(based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0)
185 VAC/165 VAC/145 VAC/135 VAC ± 5 %
(based on load percentage 100% - 80%/80% - 70%/70 - 60%/60% - 0)
300 Vac ± 5%
290 Vac ± 5%
40 Hz ~ 70 Hz
Single phase with ground
≥ 0.99 @ nominal input voltage
200/208/220/230/240 Vac
± 1%
47 ~ 53 Hz or 57 ~ 63 Hz
50 Hz ± 0.25 Hz or 60 Hz ± 0.3 Hz
(Batt. Mode)
105%~110%: UPS shuts down after 10 min at battery mode
or transfer to Bypass when the utility is normal
110%~130%: UPS shuts down after 1 min at battery mode
or transfer to Bypass when the utility is normal
>130%: UPS shuts down after 3 secs at battery mode
or transfer to Bypass when the utility is normal
3:1
≤
3% THD (Linear load)
≤
5% THD (Non-linear load)
Zero
4 ms (Typical)
Pure Sinewave
2 kVA 2 kVA
7 2FMI 96V FMI
2000 VA/1600 W
3 kVA 3 kVA
72 FMI 96 FMI
3000 VA/2400 W
