QUICK SET-UP GUIDE
2000 HR-V IBB 28AH
APPLICATIONS
3
NEW ENERGY
TO POWER
UNBOXING :
Cut the nylon belt and lift the carton box
from the top. Remove the polythene cover,
foams and lift the UPS from the lower
carton tray.
Turn on the battery circuit breaker
Connect the application input plug
to the UPS output socket, use 3-pin
6A 240 V AC plug before switching
INSTALLATION :
Step 3
Connect the UPS AC input power plug to socket before
switching the UPS on (Use 3-pin 10A or 16A 240 V AC plug
for 2 kVA.
INSTALLATION :
Step 1
Step 2
the UPS on.
www.numericups.com
2
1
