Lightspeed Access Link User Manual page 22

Media Connector Controls and Indicators
BACK PANEL
1. AUDIO INPUTS: 3.5mm stereo connectors for connecting classroom
audio sources to be played through audio system.
AUDIO OUTPUTS: 3.5mm stereo connectors for connecting to an
2.
assisted listening device (ALD) or to a computer for recording.
USB INPUT: Plug the USB-C end of the power cable into this USB port
3.
on the Media Connector.
• The USB port supplies power to Media Connector when connected
to the Media Connector power supply, or from a laptop.
• It also acts as an input for a digital audio when connected to an
audio source. Note that when the USB is used for audio input, the
other four audio input jacks are not operational.
22
Audio Inputs Audio Outputs
1 2
(Optional)
USB
V / . A
3
