Lightspeed Topcat Cascadia Installation Manual

Networked instructional audio system
Hide thumbs

Advertisement

Quick Links

Download this manual
Networked Instructional Audio System
Installation Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the Topcat Cascadia and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lightspeed Topcat Cascadia

Summary of Contents for Lightspeed Topcat Cascadia

  • Page 1 Networked Instructional Audio System Installation Guide...

  • Page 2: Overview

    OVERVIEW Important Safety Instructions Do not use the apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. Do not defeat the safety purpose of the polarized or grounding-type plug.

  • Page 3: Table Of Contents

    Optional Components INSTALLATION Installation Planning Selecting Mounting Location Topcat Cascadia Ceiling Installation (U.S. & Canada) Topcat Cascadia Installation au plafond (U.S. & Canada) Topcat Cascadia dimensions Three Options to Connect to Electrical Power Setup and Using the Clearmike Charging the Clearmike...

  • Page 4: System Components And Unpacking

    System Components and Unpacking The standard configuration includes: Topcat Cascadia Clearmike Microphone Cradle Charger Volume Control Microphone & Power Supply NOTE ON PAIRING: Topcat Cascadia , microphone(s), and Media Connector are paired together at the Lightspeed factory as required for proper operation.

  • Page 5: Optional Components

    Optional Components Optional equipment which may be part of your Topcat Cascadia system: Output Input USB Audio Power Status Media Media Connector Connector Push Audio Audio Tone Level Input Output Media Connector Sharemike Wallplate & Power Supply Handheld Microphone Audio IO Options...

  • Page 6: Installation

    Before beginning installation, make sure you have the necessary tools and materials on hand and that the area underneath the proposed Topcat Cascadia location is cleared. NOTE: Topcat Cascadia is designed for installation in a 2’ x 2’ or 2’ x 4’ suspended ceiling grid. If you do not have this type of ceiling, please contact your local Lightspeed Account Executive.

  • Page 7: Topcat Cascadia Ceiling Installation (U.s. & Canada)

    TOPCAT CASCADIA CEILING INSTALLATION (U.S. & CANADA) The dimensions of Topcat Cascadia are 1’ x 2’ and it is designed to fit into any 2’ X 4’ CEILING TILE 2’ X 2’ CEILING TILE standard 2’ x 2’ or 2’ x 4’ suspended ceiling tile grid.
  • Page 8 PREPARING TOPCAT CASCADIA (U.S. & CANADA) There are four fold out tabs on the Topcat Cascadia, two on each side of the housing. These need to be prepared before installing the system in the ceiling. Use a screwdriver to bend out tab and pliers to the bend tab out far enough that it can be hooked over the T-bar rails.
  • Page 9 Repeat for second anchor. HOOK FOLD OUT TAB OVER THE Lift the Topcat Cascadia up and lay it into the desired ceiling grid location. T-BARS CAUTION: Ensure that Topcat Cascadia is stable on the grid rails with the fold out tabs hooked over the rails.

  • Page 10: Topcat Cascadia Installation Au Plafond (U.s. & Canada)

    TOPCAT CASCADIA INSTALLATION AU PLAFOND (U.S. & CANADA) Les dimensions du Topcat Cascadia sont de 1’ x 2’ et il est conçu pour 2’ X 4’ DALLE DE PLAFOND 2’ X 2’ DALLE DE PLAFOND s’adapter à n’importe quelle grille de dalle de plafond suspendu standard de 2’...

  • Page 11: Topcat Cascadia Dimensions

    TOPCAT CASCADIA DIMENSIONS 4.4” (106mm) 11.8” (301mm) 23.7” (603mm) SIDE...
  • Page 12 PRÉPARATION DU TOPCAT CASCADIA (U.S. & CANADA) Le Topcat Cascadia est doté de quatre languettes dépliables, deux de chaque côté du boîtier. Celles-ci doivent être préparées avant l’installation du système au plafond. Utilisez un tournevis pour plier la languette et une pince pour la plier suffisamment loin pour qu’elle puisse être accrochée sur les rails de...
  • Page 13 BARRES EN T Soulevez le Topcat Cascadia et placez-le dans l’emplacement de grille de plafond souhaité. PRUDENCE: Assurez-vous que le Topcat Cascadia est stable sur les rails de la grille, les languettes rabattables étant accrochées aux rails. PLAFOND Dans le cas contraire, il risque de tomber jusqu’à ce que les câbles de sécurité...

  • Page 14: Three Options To Connect To Electrical Power

    Using copper wire attach the electrical wiring to the Topcat Cascadia ceiling module as shown. On the back can of the Topcat Cascadia, loosen the four screws holding the AC connection cover in place and rotate the cover out of the way.

  • Page 15: Option 2: Power Over Ethernet (Poe)

    Ensure the network drop for the Topcat Cascadia has the correct power available. The C25 requires a PoE+ 802.3at for full operation. Open the front panel of the Topcat Cascadia to give access to the C25 inside. There are two available ports for cables on the back can of the Topcat Cascadia, one on the back and one on the side.

  • Page 16: Option 3: External Power Connection

    When electrical AC power or PoE+ power is not available above the ceiling for BACK PANEL installation with Topcat Cascadia, a direct DC power connection is a third option using an optional 50’ DC extension cord (Part # DCPEX-NA). Remove the factory installed 24V 2.5 amp power supply by unstrapping the velcro holding it in place.
  • Page 17 DO NOT REMOVE C25 BACK PANEL SHOWING DC POWER JACK UNIT FROM TOPCAT CASCADIA Power Wall Plate Ethernet 24v/2.5a Audio Inputs Audio Digital Audio Page Relay Contact Power Class 2 Wiring Remote Output First Input Closure 24VDC / 2.5A 3.3VDC / 10mA Input Output PoE+...

  • Page 18: Setup And Using The Clearmike

    SETUP AND USING THE CLEARMIKE NOTE: This procedure is easier with two people. Ensure that Topcat Cascadia is powered on. The power LED will glow white. Remove the Clearmike from the cradle charger. The Clearmike will automatically power on and mute when it is removed from the charger.

  • Page 19: Charging The Clearmike

    The power status light will glow green to indicate that charging is complete and a full charge has been reached. Replacement Lithium Ion battery packs may only be purchased through Lightspeed Technologies (part #L3.7V).

  • Page 20: Installing Optional Equipment

    IP Paging Systems as CONNECTING THE PAGEFIRST CONNECTOR these digital signals do not produce sufficient induction current. TO C25 INSIDE TOPCAT CASCADIA SHIELDED PLENUM WIRE Strip back the outer cable jacket of the 25V/70V speaker cable to gain access to the two speaker cable conductors.

  • Page 21: Adjusting The Sensitivity

    NOTE: The PageFirst function works via current induction. The above instructions represent the most common method to achieve sufficient induction. If sufficient induction is not achieved to trigger this function, please contact Lightspeed regarding alternate installation methods. Take precautions as necessary to prevent and guard against electromagnetic and electrostatic noise interference. Unshielded and/ or poorly shielded cable,...

  • Page 22: Contact Closure

    Analog Life Safety Solutions DC VOLTAGE Partner Interface Contact Relay Page Relay Closure Input First Com NO RELAY INPUT The C25 contains an input connection to detect a signal from Fire Alarm, IP Paging System or other device. When triggered, audio from the C25 is muted to ensure emergency alerts from external systems can be heard.

  • Page 23: Media Connector Set-Up

    Media Connector Set-Up DETERMINE SET-UP LOCATION Choose a location for the Media Connector that is convenient to the classroom audio WALL MOUNTED sources and power supply. The Media Connector can be placed on a counter or wall mounted. Determine the best location for your room.

  • Page 24: Determine Location

    Audio input jacks. analog audio ports will be disabled). USB audio enables a 2-way audio link to: Power Status Media Connector Push Send audio from the computer to the Topcat Cascadia COMPUTER SETTINGS Audio Audio Tone Level Input...

  • Page 25: Volume Adjustment For The Media Connector

    Reboot Media Connector by removing and plugging in power supply. NOTE ON REGISTRATION: The Topcat Cascadia and Media Connector are paired together as a pair at the Lightspeed factory as required for proper operation. If paired Topcat Cascadia and Media Connector are separated and swapped during the installation...
  • Page 26 NOTE ON INTEGRATION: If Media Connector is not included in installation, a 3.5mm audio cable may be connected from the audio source to the audio inputs of the C25 inside the Topcat Cascadia. Take precautions as necessary to prevent and guard against electromagnetic and electrostatic noise interference.

  • Page 27: Wall Plate Installation

    • Mount the Wall Plate to the wall box or mud ring using the included screws. • Plug the RJ45 connector on the other end of the Cat5e cable into the Wall Plate port on the Topcat Cascadia. NOTE: ADD A...

  • Page 28: Certifications & Troubleshooting

    European Union Directive 2012/19/EU on Waste Electrical and Electronic Equipment (“WEEE Directive”). Please visit our website at www.Lightspeed-tek.com for more information. This product is manufactured using lead-free processes and is free of other materials harmful to the environment.

  • Page 29: Précautions De Sécurité Et Certifications

    Mettre au rebus les (RED). batteries usagées selon les instructions. Lightspeed Technologies a lancé un programme de recyclage de produits en Europe conformément à la directive de l’Union Européenne 2012/19/EU relative aux déchets d’équipements électriques et électroniques (directive «...

  • Page 30: Troubleshooting

    A blue Talk/Mute light indicates the microphone is unmuted. • If an Activate Station or Media Connector is paired with Topcat Cascadia, make sure that the volume level of the Media Connector is not turned down all the way. Slowly increase the volume level while talking into the microphone.
  • Page 32 Dedicated to Access for All We create instructional audio and video solutions that unlock student access to learning opportunities and give teachers meaningful insights into moment-by- moment learning. 11509 SW HERMAN ROAD TUALATIN, OREGON 97062 TOLL FREE: 800.732.8999 PHONE: 503.684.5538 FAX: 503.684.3197 LIGHTSPEED-TEK.COM IG0734US01-2...
