ACCESS LINK REGISTRATION GUIDE
STANDARD REGISTRATION
FLEXMIKE REGISTRATION (OTHER REGISTERED COMPONENTS IN PLACE)
(Particularly valuable when Access Link is not easily accessible)
For users adding a second Flexmike or replacing a lost or malfunctioning Flexmike.
1.
Start with the Access Link plugged in and powered on.
2.
If replacing a Flexmike, make sure the malfunctioning Flexmike is powered off.
3.
If a second Flexmike, Sharemike or Media Connector is present, power it on
and wait until it has a solid blue light ("Ready"). (For the purpose of these
instructions, it is assumed that the #1 Flexmike is the functioning Flexmike and
we are registering the #2 Flexmike.)
4.
Power on the new Flexmike. Both microphone 1 and 2 blue lights should start
blinking.
5.
Open the new Flexmike battery compartment and pull the battery out (leaving it
plugged in) to reveal the registration button.
6.
Use another registered functional component (existing Flexmike, Sharemike or
Media Connector) to trigger the registration function in Access Link.
• Using a paperclip with the end straightened out, press and hold the registration
button for 3 seconds inside the functioning Flexmike. This triggers registration in
the Access Link and the Access Link's 1 and 2 amber lights will begin blinking.
7.
Briefly press the registration button on the new or replacement Flexmike. The 1 and 2 blue lights will start blinking alternately.
8.
After several seconds, the 2 light on the Access Link will turn solid
and the 2 light on the Flexmike will remain blinking, then turn
solid.
9.
The registration is complete. You can begin speaking into the new
Flexmike to verify there is audio.
10.
Place system ID number (attached to the Access Link Quickstart
Guide) on the new Flexmike.
NOTE: if at any point, the Access Link or Flexmike lights begin
blinking rapidly, that indicates a registration error. Turn the new
Flexmike off and repeat steps 4-9.
Solid light
Power On
(Existing Good Flexmike)
Blinking lights
MICROPHONE
AUDIO IN
TONE
POWER
1
2
MIN
MAX
MIN
MAX
TREBLE
BASS
MICROPHONE
AUDIO IN
TONE
POWER
1
2
MIN
MAX
MIN
MAX
TREBLE
BASS
USB POWER
5V/0.2A
REGISTER
USB POWER
+
MIC
LINE
5V/1.5A
AUDIO IN
BAL. AUDIO OUT
AUDIO OUT
AUDIO OUT/DC IN
Blinking lights
Power On
(NEW Flexmike)
Registration
Button
Solid lights
Apply to system components to indicate which parts are registered
as a system. Keep registered items together when storing away.
334-0162-02-00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
RETAIN EXTRA LABELS IN THE EVENT A COMPONENT IS REPLACED OR ADDED.
Registration ID Labels
10101
00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
