Lightspeed Access Link Operation Instructions

ACCESS LINK WITH OPTIONAL ACTIVATE

DAILY OPERATION INSTRUCTIONS

PLEASE FOLLOW ACCESS LINK SET UP INSTRUCTIONS ON OPPOSITE PAGE
ENSURE THE SYSTEM IS POWERED ON
1. Locate the 24V power supply and power cable and connect the AC power cord into the
DC power supply. Insert the DC connector into the DC Power jack on the back and
plug the AC power cord into an electrical outlet.
2. Press the Activate Station power button to power on the Access Link. When powered
on, the blue LED will glow.

USING THE FLEXMIKE

3. Remove microphone from charger and place the microphone around your neck.
Ensure the top of the microphone is at the collarbone.
4. Press the power/mute button. The teacher status will turn blue, indicating the
microphone is active.
5. Microphone volume may be adjusted at the microphone by using the Up/
Down buttons on the side of the Flexmike. It may also be adjusted by using the
Microphone volume buttons on the front of the Activate.
6. For recording video, audio and images, ensure your mobile device is paired with
Activate. If not paired, refer to the Mobile Device Pairing Quickstart guide.

USING A WIRELESS AUDIO LINK

7. Plug your external audio equipment (for example, laptop), into one of the input jacks on
the back of the Activate labeled "Aux Input" using a 3.5mm patch cable.
8. Adjust volume at the audio source. If necessary, further volume adjustment may be
made using the Audio In volume buttons on the front of the Activate.

CHARGE FLEXMIKE NIGHTLY

9. Place the Flexmike into the charger. The power button light will glow red and the Mic status
light will glow blue. When Flexmike is fully charged, the power button light on the mic will
change to green.
For futher instructions on capturing audio and video using the Activate App, and for complete operating
instructions, go to www.lightspeed-tek.com/AL-usermanual (or scan the 2D barcode below).
L ig h t spe e d Techn ol og ies
w w w. l i g h t s pe ed- tek .co m / 80 0.73 2.8999 / 503.684.5538
.
2
9
QS0541US01-2
1
Power / Mute
4
5
3
7
2
8
