2. Specifications

2.1.

Core System

CPU
Cache
Memory
Chipset
Embedded BIOS
CPU and Chipset
Combinations
2.2.

Expansion Busses

PCI Express
Other
Specifications
7th Generation Intel® Core™ and and Xeon® E3-15xx v6 processor
(formerly "Kaby Lake-H")
•
Intel® Xeon® E3-1505M v6 3.0/4.0GHz (Turbo), 45W/35W(cTDP, 4C/GT2)
•
Intel® Xeon® E3-1505L v6 2.2/3.0GHz (Turbo), 25W (4C/GT2)
•
Intel® Core™ i7-7820EQ 3.0/3.7GHz (Turbo), 45W/35W(cTDP, 4C/GT2)
•
Intel® Core™ i5-7440EQ 2.9/3.6GHz (Turbo), 45W/35W(cTDP, 4C/GT2)
•
Intel® Core™ i5-7442EQ 2.1/2.9GHz (Turbo), 25W (4C/GT2)
•
Intel® Core™ i3-7100E 2.9GHz, 35W (2C/GT2)
•
Intel® Core™ i3-7102E 2.1GHz, 25W (2C/GT2)
Supporting: Intel® VT, Intel® TXT, Intel® SSE4.2, Intel® HT Technology, Intel® 64
Architecture, Execute Disable Bit, Intel® Turbo Boost Technology 2.0, Intel® AVX2, Intel®
AES-NI, PCLMULQDQ Instruction, Intel® Device Protection Technology with Intel®
Secure Key, Intel® TSXNI (availability of features may vary between processor SKUs)
Note: Power Limit option available in BIOS settings (see 7.3.1) to adjust TDP from 45W to
20-30W (45W SKUs only).
8MB for Xeon®/Core™ i7, 6MB for Core™ i5, 3MB for Core™ i3
Dual channel ECC or non-ECC 2133/2400 MHz DDR4 memory up to 32GB in dual
stacked SODIMM sockets
Note: Only Xeon® and Core™ i3 processors paired with the CM238 Chipset can support
both of ECC and non-ECC memory. Other processor/chipset combinations support non-
ECC memory.
Mobile Intel® QM175, HM175 and CM238 Chipset (HM175 does not support Intel® AMT)
AMI EFI with CMOS backup in 16MB SPI BIOS with Intel® AMT 11 support
Express-KL (non-ECC memory support)
•
Core™ i7/i5 with QM175 Chipset
•
Core™ i3 with HM175 Chipset
Express-KLE (ECC memory support and non-ECC memory support)
•
Xeon® with CM238 Chipset
•
Core™ i3 with CM238 Chipset (supported by project basis; please contact your ADLINK
representative)
Note: Combinations not listed above may be supported by project basis. Please contact
your ADLINK representative.
PCI Express x16 Gen3 (can be configured to 1x16, 2 x8 or 1 x8 with 2 x4)
6 PCI Express x1 Gen3 (AB): Lanes 0/1/2/3/4/5
2 PCI Express x1 Gen3 (CD): Lane 6/7
Note: PCIe lanes 0/1/2/3 can also be configured to x2, x4 PCIe lanes 4/5/6/7 can also be
configured to x2, x4.
•
LPC bus
•
SMBus (system)
• 2
I C (user)
