3.4.5. PCI Express Graphics x16 (PEG)
Signal Pin
PEG_RX0+ C52
PEG_RX0- C53
PEG_RX1+ C55
PEG_RX1- C56
PEG_RX2+ C58
PEG_RX2- C59
PEG_RX3+ C61
PEG_RX3- C62
PEG_RX4+ C65
PEG_RX4- C66
PEG_RX5+ C68
PEG_RX5- C69
PEG_RX6+ C71
PEG_RX6- C72
PEG_RX7+ C74
PEG_RX7- C75
PEG_RX8+ C78
PEG_RX8- C79
PEG_RX9+ C81
PEG_RX9- C82
PEG_RX10+ C85
PEG_RX10- C86
PEG_RX11+ C88
PEG_RX11- C89
PEG_RX12+ C91
PEG_RX12- C92
PEG_RX13+ C94
PEG_RX13- C95
PEG_RX14+ C98
PEG_RX14- C99
PEG_RX15+ C101
PEG_RX15 C102
PEG_TX0+ D52
PEG_TX0- D53
PEG_TX1+ D55
PEG_TX1- D56
PEG_TX2+ D58
PEG_TX2- D57
PEG_TX3+ D61
PEG_TX3- D62
PEG_TX4+ D65
PEG_TX4- D66
PEG_TX5+ D68
PEG_TX5- D69
PEG_TX6+ D71
PEG_TX6- D72
PEG_TX7+ D74
PEG_TX7- D75
PEG_TX8+ D78
PEG_TX8- D79
PEG_TX9+ D81
PEG_TX9- D82
PEG_TX10+ D85
PEG_TX10- D86
PEG_TX11+ D88
PEG_TX11- D89
PEG_TX12+ D91
PEG_TX12- D92
PEG_TX13+ D94
PEG_TX13- D95
PEG_TX14+ D98
PEG_TX14- D99
PEG_TX15+ D101
Pinouts and Signal Descriptions
Description
PCI Express Graphics transmit differential
pairs.
PCI Express Graphics receive differential
pairs.
I/O PU/PD Comment
I PCIE AC couple off
module
O PCIE AC couple on
module
