- Page 1 A pplica t io n s E n g in e e r in g Powerful Processors – Easy to Use™ SKP16C62P User's Manual Rev. 1.0 December 2003 w w w.renesas.com Downloaded from Elcodis.com electronic components distributor...
-
Page 2: Table Of Contents
4.4.3 KD30 Debugger ....................6 4.4.4 FoUSB (Flash-over-USB™) Programmer............. 6 5.0 Hardware........................7 5.1 SKP16C62P Board ....................7 5.2 SKP16C62P Board Block Diagram................8 5.3 M16C/62P Group of Microcontrollers ..............8 5.4 SKP16C62P Board Jumper Configuration............... 9 5.4.1 JP1: MCU (U1) Power ..................9 5.4.2 JP2: Xout ...................... -
Page 3: Introduction
The ICD and firmware provide a convenient USB (Universal Serial Bus) interface between the SKP16C62P board and the host PC. This interface reduces resource requirements on the M16C/62P MCU, allows faster code downloads and, can also be used with many other Renesas Flash MCU’s, SKP’s, and user’s target board. -
Page 4: Contents Of Product Package
Applications Engineering 2.0 Contents of Product Package This section describes the contents of the SKP16C62P product package. When unpacking your SKP16C62P, please check to see that all products listed below are included. 2.1 SKP16C62P StarterKit Plus Product List Table 2-1 lists the products included in the SKP16C62P. -
Page 5: Limited Guarantee And Support
Applications Engineering 3.0 Limited Guarantee and Support Renesas Technology America, Inc., warrants the SKP16C62P to be free from component or assembly defect for a period of 180 days from the date of purchase. Settlement is limited to repair or replacement of the product only. Renesas Technology America, Inc., does not assume any liability arising out of the application or use of any product, circuit or procedure described herein. -
Page 6: System Connectivity
Figure 4-1 SKP16C62P System Connectivity 4.1 Host Computer Requirements The minimum requirement to be able to use the software that comes with the SKP16C62P is a PC with a USB port and Microsoft Windows 98, ME, 2000, or XP. Note: For Windows 95 and NT, that do not support USB, please contact Renesas representative or email techsupport.rta@renesas.com... -
Page 7: Software Development Tools
) Programmer 4.4.4 User programs can run on the SKP16C62P board without the host computer running KD30 by programming the on-board M16C/62P flash MCU with firmware using FoUSB Programmer. It can also be used to program other Renesas’ M16C Flash MCU’s and 740 series MCU’s. -
Page 8: Hardware
Applications Engineering 5.0 Hardware 5.1 SKP16C62P Board Figure 5-1 shows the SKP16C62P Board with major components identified. Expansion Port Power Reset 8-character x 2-line LCD Thermistor Analog Adjust Pot Contrast Xout MCU Power M16C/62P 12MHz Crystal M30626FHPGP User LED's RTA-FoUSB-... -
Page 9: Skp16C62P Board Block Diagram
CMOS process with an M16C/60 series CPU core. The datasheet for the M16C/62P group of microcontrollers can be found under C:\MTOOL \SKP16C62P\Docs folder of your PC after SKP software installation or from the Start menu (Start > Programs > RENESAS-TOOLS > SKP16C62P > Document Descriptions. -
Page 10: Skp16C62P Board Jumper Configuration
Applications Engineering 5.4 SKP16C62P Board Jumper Configuration 5.4.1 JP1: MCU (U1) Power JP1 is used to connect the power/Vcc pins of the M16C/62P MCU to the Vcc of the board. It can be used to measure current/power consumption of the MCU during various modes of operation. -
Page 11: System Limitations
Applications Engineering 6.0 System Operation & Limitations The SKP16C62P provides sophisticated debugging features at a low cost but it does have some limitations when used with the KD30 Debugger and ICD. Section 6.1 introduces the kernel (ROM monitor) program and what it is for. The limitations when this kernel is running with the user program are listed in table 6-1. -
Page 12: Status After Reset
255. The user reset vector is re-mapped to address FFFD8h by the kernel. 6.4 Status After Reset Table 6-2 lists the values of the registers initialized by the kernel program when the SKP16C62P starter board is reset. The register status depends on the microcomputer’s internal operation performed after a reset. -
Page 13: Limitations On Interrupts
(approximately 2000 BCLK cycles for each 16 bytes of data displayed in the window are used per window update). The user must determine whether or not this behavior is acceptable. SKP16C62P User’s Manual Rev. 1.0 12 / 22 December 2003 Downloaded from Elcodis.com... -
Page 14: Performing Debug Using Symbols
To enable the [-g] option, perform the following: • Open the workspace and project in HEW. • Select [Renesas M16C Standard Toolchain] from Options pull-down menu. • Click on Link tab. • Select [Output] under the [Category] list box. -
Page 15: Skp16C62P Board Specifications
[D3] (Green): User output (connected to P7_2) 2-line x 8-character LCD with KS0066 controller IC 7.2 Power Supply Requirements The SKP16C62P Board will draw 35mA (max). With the ICD, the current draw will be about 75mA. 7.3 Operating Environment Table 7-3 lists the environmental conditions for using and storing the SKP16C62P board. When storing the board, place it in a conductive bag and then in the packing box your product was shipped in from the factory. -
Page 16: Appendix A. Troubleshooting Guide
KD30 or FoUSB Programmer applications. This section also discusses the countermeasures and solutions to resolve these problems. If, for any reason, you cannot resolve the problem, please contact your Renesas representative for assistance. A.1 USB Driver Problems This section discusses the usual problems with the driver installation and how to fix it. -
Page 17: Kd30 Problems
Please connect the ICD to your PC. Note: Regardless of whether the ICD is bus or target- powered, please connect target board to ICD board first before plugging the USB cable to your PC. Please see section 4 on system (SKP16C62P) connectivity. •... - Page 18 • Do a hardware reset. User-program runaway may be corrupting kernel RAM or interrupt vectors, flags, etc. Close KD30, hit S1 on the SKP16C62P to reset the board, and then restart KD30. Download Issues • Filenames or directory names contain spaces or special characters.
-
Page 19: Installing Required Files Manually
(3) Run the HEW installer, ‘setup.exe’, from the \Tools\HEW folder on the SKP CD. (4) Run the NC30 installer, ‘nc30wa_entry.exe’, from the \Tools\NC30WA folder on the SKP (5) Create an SKP16C62P folder under C:\MTOOL on your PC and then copy the directories from the \SKP16C62P\files folder on the SKP CD to this folder. -
Page 20: Appendix B. Reference Manuals
SKP16C62P Board Schematic Schematic diagram for the SKP16C62P Starter Kit board. SKP16C62P Board BOM Bill of materials for the SKP16C62P Starter Kit board. M16C/62P Group Data Sheet Operation and Specifications for the M16C/62P MCU’s. ANSI C-language programming guide for the... -
Page 21: Appendix C. Expansion Headers
P7_7, TA3in P6_0, CTS0 P6_1, CLK0 P6_2, RxD0, SCL0 P6_3, TxD0, SDA0 P6_4, CTS1, CLKS1 P6_5, CLK1 P6_6, RxD1, SCL1 P6_7, TxD1, SDA1 Vref BYTE SKP16C62P User’s Manual Rev. 1.0 20 / 22 December 2003 Downloaded from Elcodis.com electronic components distributor... -
Page 22: Appendix D. Skp Board Dimensions
Applications Engineering Appendix D. SKP Board Dimensions SKP16C62P User’s Manual Rev. 1.0 21 / 22 December 2003 Downloaded from Elcodis.com electronic components distributor... -
Page 23: Appendix E. Rta-Fousb-Mon (Icd)
