POWER SUPPLY:

The devices can be powered at 15...21V AC and 18...35V DC. The consumption depends to the code of the device. For more details see the
two tables below.
Consumption at 24V DC:
ADFweb.com S.r.l.
VAC
Vmin Vmax
15V
Device
HD67695-B2-1-10
HD67695-B2-3-25
HD67695-B2-15-50
HD67695-B2-30-75
HD67695-B2-50-100
* This value is with all the Slave M-Bus devices of the code connected to the line
Document code: MN67694_ENG
VDC
Vmin Vmax
21V 18V 35V
No Load [W/VA]
3.5
Caution: Not reverse the polarity power
User Manual M-Bus / BACnet/IP
Revision 1.000
Full Load [W/VA]*
4
5
8
14
30
HD67695-B2-xx-xxx
