User Manual BACnet / DeviceNet Slave
Document code: MN67681_ENG
For others BACnet products see also the following link:
Converter BACnet to
www.adfweb.com?Product=HD67056
www.adfweb.com?Product=HD67671
www.adfweb.com?Product=HD67672
www.adfweb.com?Product=HD67673
www.adfweb.com?Product=HD67674
www.adfweb.com?Product=HD67675
www.adfweb.com?Product=HD67676
www.adfweb.com?Product=HD67677
www.adfweb.com?Product=HD67678
www.adfweb.com?Product=HD67679
www.adfweb.com?Product=HD67680
www.adfweb.com?Product=HD67681
www.adfweb.com?Product=HD67682
www.adfweb.com?Product=HD67683
www.adfweb.com?Product=HD67684
Do you have an your customer protocol?
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
in India
in India
in India
in India
Revision 1.000
Pagina 1 di 21
(M-Bus Master)
(Modbus Master)
(Modbus Slave)
(Modbus TCP Master)
(Modbus TCP Slave)
(PROFIBUS Master)
(PROFIBUS Slave)
(CAN)
(CANopen)
(PROFINET)
(DeviceNet Master)
(DeviceNet Slave)
(EtherNet/IP)
(NMEA 2000)
(Ethernet)
Phone +39.0438.30.91.31
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ADF Web AXIS HD67681-A1
Summary of Contents for ADF Web AXIS HD67681-A1
- Page 1 User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 1 di 21 Industrial Electronic Devices User Manual Revision 1.000 English BACnet / DeviceNet Slave - Converter (Order Code: HD67681-A1) for Website information: www.adfweb.com?Product=HD67681 for Price information: www.adfweb.com?Price=HD67681-A1 Benefits and Main Features: For others BACnet products see also the following link: Converter BACnet to...
-
Page 2: Table Of Contents
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 2 di 21 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX Updated UPDATED DOCUMENTATION... -
Page 3: Security Alert
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 3 di 21 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation. -
Page 4: Example Of Connection
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 4 di 21 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 5: Connection Scheme
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 5 di 21 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67681-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 6: Characteristics
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 6 di 21 Industrial Electronic Devices CHARACTERISTICS: The HD67681-A1 is a BACnet / DeviceNet Slave Converter. It allows the following characteristics: Up to 2048 BACnet objects (Read+Write); Triple isolation between BACnet - Power Supply, BACnet - DeviceNet, Power Supply – DeviceNet; Two-directional information between BACnet bus and DeviceNet bus;... -
Page 7: Power Supply
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 7 di 21 Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax... -
Page 8: Function Modes
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 8 di 21 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip2 of Dip-Switch A’: The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip2 of Dip-Switch A’... -
Page 9: Leds
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 9 di 21 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state... -
Page 10: Devicenet
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 10 di 21 Industrial Electronic Devices DeviceNet: To terminate the DeviceNet line with a 120Ω resistor it is necessary that the Dip1 of ‘Dip-Switch B’ is at ON position. Cable characteristics: DC parameter: Impedance... -
Page 11: Bacnet
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 11 di 21 Industrial Electronic Devices BACNET: The BACnet connection must be made using Connector3 and/or Connector4 of HD67681-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. -
Page 12: Use Of Compositor Sw67681
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 12 di 21 Industrial Electronic Devices USE OF COMPOSITOR SW67681: To configure the Converter, use the available software that runs with Windows, called SW67681. It is downloadable on the site www.adfweb.com and its operation is described in this document. -
Page 13: Set Communication
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 13 di 21 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, BACnet and DeviceNet. By Pressing the “Set Communication” button from the main window for SW67681 (Fig. 2) the window “Set Communication”... -
Page 14: Set Bacnet Access
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 14 di 21 Industrial Electronic Devices SET BACNET ACCESS: By Pressing the “Set BACnet Access ” button from the main window for SW67681 (Fig. 2) the window “BACnet Set Access” appears (Fig. The window is divided in two parts, the “BACnet in Read”... -
Page 15: Objects Map
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 15 di 21 Industrial Electronic Devices Is possible to insert directly the Unit (using its unique number) by compiling the “Selected BACnet Engineering Unit” field; or by selecting with the fields “Select the Type”... -
Page 16: Update Device
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 16 di 21 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button it is possible to load the created Configuration into the device; and also the Firmware, if is necessary. If you don’t know the actual IP address of the device you have to use this procedure: Turn off the Device;... - Page 17 User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 17 di 21 Industrial Electronic Devices If you know the actual IP address of the device you have to use this procedure: Turn on the Device with the Ethernet cable inserted; Insert the actual IP of the Converter;...
-
Page 18: Mechanical Dimensions
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 18 di 21 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 8: Mechanical dimensions scheme for HD67681-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 19: Ordering Informations
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 19 di 21 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD67681 – A 1 Connectors Type 1: Removable 5mm Screw Terminal Enclosure Type A: 1M, 35mm DIN Rail mounting Device Family... -
Page 20: Disclaimer
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 20 di 21 Industrial Electronic Devices DISCLAIMER All technical content within this document can be modified without notice. The content of the document content is a recurring audit. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 21: Warranties And Technical Support
User Manual BACnet / DeviceNet Slave Document code: MN67681_ENG Revision 1.000 Pagina 21 di 21 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: 1) Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
