Industrial Electronic Devices
User Manual
Revision 1.000
English
EtherNet/IP Master / Modbus slave - Converter
(Order Code: HD67669-A1)
For Website information:
www.adfweb.com?Product=HD67669
For Price information:
www.adfweb.com?Price=HD67669-A1
Benefits and Main Features:
Very easy to configure
Triple Electrical isolation
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com S.r.l.
User Manual EtherNet/IP Master/ Modbus slave
Document code: MN67669_ENG
For other EtherNet/IP Master products see also the following link:
Converter EtherNet/IP Master to
www.adfweb.com?Product=HD67B38
www.adfweb.com?Product=HD67D24
www.adfweb.com?Product=HD67E26
www.adfweb.com?Product=HD67158
www.adfweb.com?Product=HD67643
www.adfweb.com?Product=HD67645
www.adfweb.com?Product=HD67646
www.adfweb.com?Product=HD67647
www.adfweb.com?Product=HD67661
www.adfweb.com?Product=HD67665
www.adfweb.com?Product=HD67667
www.adfweb.com?Product=HD67668
www.adfweb.com?Product=HD67689
www.adfweb.com?Product=HD67743
www.adfweb.com?Product=HD67806
www.adfweb.com?Product=HD67955
www.adfweb.com?Product=HD67973
Revision 1.000
Page 1 of 27
(OPC UA Server)
(LoRaWAN)
(EtherCAT)
(SNMP Agent)
(PROFIBUS Slave)
(CAN)
(CANopen)
(DeviceNet Slave)
(PROFINET)
(Modbus TCP Slave)
(Serial)
(Ethernet)
(BACnet Slave)
(IEC 61850 Server)
(KNX)
(MQTT)
(IO-Link Slave)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ADF Web HD67669-A1
Summary of Contents for ADF Web HD67669-A1
- Page 1 Page 1 of 27 Industrial Electronic Devices User Manual Revision 1.000 English EtherNet/IP Master / Modbus slave - Converter (Order Code: HD67669-A1) For Website information: www.adfweb.com?Product=HD67669 For Price information: www.adfweb.com?Price=HD67669-A1 Benefits and Main Features: For other EtherNet/IP Master products see also the following link:...
-
Page 2: Table Of Contents
User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 2 of 27 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Page Dear customer, we thank you for your attention and we remind you that INDEX you need to check that the following document is: UPDATED DOCUMENTATION Updated REVISION LIST... -
Page 3: Security Alert
User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 3 of 27 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 4 of 27 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com S.r.l. -
Page 5: Connection Scheme
User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 5 of 27 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67669-232-A1 ADFweb.com S.r.l. - Page 6 User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 6 of 27 Industrial Electronic Devices Figure 1b: Connection scheme for HD67669-422-A1 ADFweb.com S.r.l.
- Page 7 User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 7 of 27 Industrial Electronic Devices Figure 1c: Connection scheme for HD67669-485-A1 ADFweb.com S.r.l.
-
Page 8: Characteristics
Revision 1.000 Page 8 of 27 Industrial Electronic Devices CHARACTERISTICS: The HD67669-A1 are EtherNet/IP Master / Modbus slave - Converters. It allows for the following characteristics: Isolation between Ethernet – Power Supply; Two-directional information between EtherNet/IP bus and Modbus bus;... -
Page 9: Power Supply
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67669-A1 Caution: Do not reverse the polarity power HD67669-A1 ADFweb.com S.r.l. -
Page 10: Function Modes
User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 10 of 27 Industrial Electronic Devices FUNCTION MODES: The device has got two function modes depending on the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip1 of Dip-Switch A’... -
Page 11: Leds
User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 11 of 27 Industrial Electronic Devices LEDS: The device has got seven LEDs that are used to give information about the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode ON: Device powered... -
Page 12: Ethernet
ETHERNET: The updating of the converter and EtherNet/IP communication must be made using Connector3 and Connector4 of the HD67669-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. -
Page 13: Use Of Compositor Sw67669
User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 13 of 27 Industrial Electronic Devices USE OF COMPOSITOR SW67669: To configure the Converter, use the available software that runs with Windows called SW67669. It is downloadable on the site www.adfweb.com and its operation is described in this document. -
Page 14: New Configuration / Open Configuration
User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 14 of 27 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “EtherNet/IP Master / Modbus slave - Converter”... -
Page 15: Software Options
User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 15 of 27 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. - Page 16 User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 16 of 27 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
-
Page 17: Set Communication
User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 17 of 27 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, EtherNet/IP and Modbus slave. By Pressing the “Set Communication” button from the main window for SW67669 (Fig. 2) the window “Set Communication”... -
Page 18: Ethernet/Ip Access
User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 18 of 27 Industrial Electronic Devices ETHERNET/IP ACCESS: By Pressing the “EtherNet/IP Access” button from the main window for SW67669 (Fig. 2) the window “Set EtherNet/IP Master Access” appears (Fig. - Page 19 User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 19 of 27 Industrial Electronic Devices In the field “Dim Header T > O” the dimension of the header for the Target to Originator data direction is defined; In the field “Dim Header O >...
-
Page 20: Update Device
User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 20 of 27 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port. If you don’t know the actual IP address of the device you have to use this procedure: Turn OFF the Device;... - Page 21 User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 21 of 27 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67669 device. Warning: If Fig.
-
Page 22: Modbus Map
User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 22 of 27 Industrial Electronic Devices MODBUS MAP: On Modbus side, the map is created automatically. In relation to the configuration defined, it is possible to have two different maps. Read with Input Register / Status Function not enabled Data in reading: Type... - Page 23 User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 23 of 27 Industrial Electronic Devices Read with Input Register / Status Function enabled Data in reading: Type Address Function Description Input Bytes 0-1 of EtherNet/IP side Input Register Input Bytes 2-3 of EtherNet/IP side Input Register Input Bytes 4-5 of EtherNet/IP side...
-
Page 24: Mechanical Dimensions
User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 24 of 27 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 7: Mechanical dimensions scheme for HD67669-xxx-A1 ADFweb.com S.r.l. -
Page 25: Ordering Informations
User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 25 of 27 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD67669 – XXX - A 1 Connectors Type 1: Removable 5mm Screw Terminal Enclosure Type A: 1M, 35mm DIN Rail mounting... -
Page 26: Disclaimer
User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 26 of 27 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 27: Warranties And Technical Support
User Manual EtherNet/IP Master/ Modbus slave Document code: MN67669_ENG Revision 1.000 Page 27 of 27 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
