Industrial Electronic Devices
User Manual
Revision 1.000
English
EtherNet/IP / Modbus TCP Slave - Converter
(Order Code: HD67663-A1)
For Website information:
www.adfweb.com?Product=HD67663
For Price information:
www.adfweb.com?Price=HD67663-A1
Benefits and Main Features:
Very easy to configure
Electrical isolation
Two Ethernet ports (for Modbus TCP / EtherNet/IP)
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com S.r.l.
User Manual EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG
For other EtherNet/IP products see also the following link:
Converter EtherNet/IP to
www.adfweb.com?Product=HD67077
www.adfweb.com?Product=HD67595
www.adfweb.com?Product=HD67597
www.adfweb.com?Product=HD67598
www.adfweb.com?Product=HD67599
www.adfweb.com?Product=HD67589
www.adfweb.com?Product=HD67591
www.adfweb.com?Product=HD67591
www.adfweb.com?Product=HD67592
www.adfweb.com?Product=HD67592
Do you have your customer protocol? Then go to:
www.adfweb.com?Product=HD67003
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
Revision 1.000
Page 1 of 24
(M-Bus)
(CAN)
(DeviceNet Master)
(DeviceNet Slave)
(J1939)
(NMEA 2000)
(Modbus Master RS232)
(Modbus Master RS485)
(Modbus Slave RS232)
(Modbus Slave RS485)
Advertisement
Table of Contents
Related Manuals for ADF Web HD67663-A1
Summary of Contents for ADF Web HD67663-A1
- Page 1 Revision 1.000 Page 1 of 24 Industrial Electronic Devices User Manual Revision 1.000 English EtherNet/IP / Modbus TCP Slave - Converter (Order Code: HD67663-A1) For Website information: www.adfweb.com?Product=HD67663 For Price information: www.adfweb.com?Price=HD67663-A1 Benefits and Main Features: Very easy to configure...
-
Page 2: Table Of Contents
User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 2 of 24 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Page Dear customer, we thank you for your attention and we remind you that INDEX you need to check that the following document is: UPDATED DOCUMENTATION Updated REVISION LIST... -
Page 3: Security Alert
User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 3 of 24 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 4 of 24 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com S.r.l. -
Page 5: Connection Scheme
User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 5 of 24 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67663-A1 ADFweb.com S.r.l. -
Page 6: Characteristics
Page 6 of 24 Industrial Electronic Devices CHARACTERISTICS: The HD67663-A1 is a EtherNet/IP / Modbus TCP Slave Converter. It allows for the following characteristics: Up to 500 bytes in reading and 500 bytes in writing; Isolation between Modbus/EtherNet/IP - Power Supply;... -
Page 7: Power Supply
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67663-A1 Caution: Do not reverse the polarity power HD67663-A1 ADFweb.com S.r.l. -
Page 8: Function Modes
User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 8 of 24 Industrial Electronic Devices FUNCTION MODES: The device has got two function modes depending on the position of the ‘Dip2 of Dip-Switch A’: The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip2 of Dip-Switch A’... -
Page 9: Leds
User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 9 of 24 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information about the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state... -
Page 10: Ethernet/Ip / Modbus Tcp
ETHERNET/IP / MODBUS TCP: The EtherNet/IP and Modbus TCP connection must be made using Connector3 and/or Connector4 of HD67663-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. -
Page 11: Use Of Compositor Sw67663
User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 11 of 24 Industrial Electronic Devices USE OF COMPOSITOR SW67663: To configure the Converter, use the available software that runs with Windows called SW67663. It is downloadable on the site www.adfweb.com and its operation is described in this document. -
Page 12: New Project / Open Project
User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 12 of 24 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “EtherNet/IP / Modbus TCP Slave - Converter”... -
Page 13: Software Options
User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 13 of 24 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. -
Page 14: Set Communication
User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 14 of 24 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, EtherNet/IP and Modbus TCP. By Pressing the “Set Communication” button from the main window for SW67663 (Fig. 2) the window “Set Communication”... -
Page 15: Update Device
User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 15 of 24 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. If you don’t know the actual IP address of the device you have to use this procedure: Turn off the Device;... - Page 16 User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 16 of 24 Industrial Electronic Devices Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67663 device.
-
Page 17: Mechanical Dimensions
User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 17 of 24 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 7: Mechanical dimensions scheme for HD67663-A1 ADFweb.com S.r.l. -
Page 18: Ordering Informations
Enclosure Type A: 1M, 35mm DIN Rail mounting Device Family HD67663: EtherNet/IP / Modbus TCP Slave - Converter Order Code: HD67663-A1 EtherNet/IP / Modbus TCP Slave - Converter ACCESSORIES: Order Code: AC34001 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V AC Order Code: AC34002 35mm Rail DIN - Power Supply 110V AC 50/60Hz –... -
Page 19: Plc Configuration
User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 19 of 24 Industrial Electronic Devices PLC CONFIGURATION: The configuration and commissioning of the EtherNet/IP Converter as described on the following pages was accomplished with the help of the “RSLogix 5000”... - Page 20 “HD67663” and the IP-address assigned is 192.168.0.5. For the Comm Format “Data – SINT” shall be selected as the data type. The HD67663-A1 can uses up to 496 bytes for input assembly instance 101 and 496 bytes for output assembly instance 100.
- Page 21 User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 21 of 24 Industrial Electronic Devices 4) After the configuration is completed, the controller tags are created. ADFweb.com S.r.l.
- Page 22 User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 22 of 24 Industrial Electronic Devices 5) With “RSLinks Classic Lite”, after have done a network scan (RSWho), and finding the EtherNet/IP device, it is possible to load the EDS file for the device in order to have the “Module Info”...
-
Page 23: Disclaimer
User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 23 of 24 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 24: Warranties And Technical Support
User Manual EtherNet/IP / Modbus TCP Slave Document code: MN67663_ENG Revision 1.000 Page 24 of 24 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
