User Manual
Revision 1.001
English
BACnet / J1939 - Converter
(Order Code: HD67685-IP-A1, HD67685-MSTP-A1,
HD67685-MSTP-B2)
for Website information:
www.adfweb.com?Product=HD67685
for Price information:
www.adfweb.com?Price=HD67685-IP-A1
www.adfweb.com?Price=HD67685-MSTP-A1
www.adfweb.com?Price=HD67685-MSTP-B2
Benefits and Main Features:
Electrical isolation
Two BACnet ports
Temperature range: -40°C/85°C (-40°F/185°F)
User Manual
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual BACnet Slave / J1939
Document code: MN67685_ENG
For others BACnet products see also the following link:
Converter BACnet to
www.adfweb.com?Product=HD67056
www.adfweb.com?Product=HD67086
www.adfweb.com?Product=HD67170
www.adfweb.com?Product=HD67670
www.adfweb.com?Product=HD67671
www.adfweb.com?Product=HD67673
www.adfweb.com?Product=HD67674
www.adfweb.com?Product=HD67675
www.adfweb.com?Product=HD67676
www.adfweb.com?Product=HD67677
www.adfweb.com?Product=HD67678
www.adfweb.com?Product=HD67679
www.adfweb.com?Product=HD67680
www.adfweb.com?Product=HD67681
www.adfweb.com?Product=HD67682
www.adfweb.com?Product=HD67683
www.adfweb.com?Product=HD67689
www.adfweb.com?Product=HD67693
www.adfweb.com?Product=HD67738
www.adfweb.com?Product=HD67767
www.adfweb.com?Product=HD67802
www.adfweb.com?Product=HD67833
www.adfweb.com?Product=HD67865
www.adfweb.com?Product=HD67901
www.adfweb.com?Product=HD67938
www.adfweb.com?Product=HD67966
www.adfweb.com?Product=HD67B11
www.adfweb.com?Product=HD67B32
www.adfweb.com?Product=HD67B81
www.adfweb.com?Product=HD67C56
www.adfweb.com?Product=HD67D17
www.adfweb.com?Product=HD67E06
www.adfweb.com?Product=HD67E56
www.adfweb.com?Product=HD67F17
Do you have an your customer protocol?
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
Revision 1.001
Pagina 1 di 33
(M-Bus Master)
(M-Bus Wireless)
(SNMP Manager)
(DMX)
(Modbus Master)
(Modbus TCP Master)
(Modbus TCP Slave)
(PROFIBUS Master)
(PROFIBUS Slave)
(CAN)
(CANopen)
(PROFINET Slave)
(DeviceNet Master)
(DeviceNet Slave)
(EtherNet/IP Slave)
(NMEA 2000)
(EtherNet/IP Master)
(SNMP Agent)
(IEC61850 Server)
(IEC61850 Client)
(KNX)
(DALI)
(IO-Link Master)
(HART)
(MQTT)
(IO-Link Slave)
(OPC UA Client)
(OPC UA Server)
(PROFINET Master)
(EnOcean)
(LoRaWAN)
(EtherCAT Slave)
(EtherCAT Master)
(LoRaWAN Gateway)
Phone +39.0438.30.91.31
Advertisement
Related Manuals for ADF Web HD67685-IP-A1
Summary of Contents for ADF Web HD67685-IP-A1
- Page 1 (SNMP Manager) www.adfweb.com?Product=HD67670 (DMX) www.adfweb.com?Product=HD67671 (Modbus Master) BACnet / J1939 - Converter www.adfweb.com?Product=HD67673 (Modbus TCP Master) www.adfweb.com?Product=HD67674 (Modbus TCP Slave) (Order Code: HD67685-IP-A1, HD67685-MSTP-A1, www.adfweb.com?Product=HD67675 (PROFIBUS Master) HD67685-MSTP-B2) www.adfweb.com?Product=HD67676 (PROFIBUS Slave) www.adfweb.com?Product=HD67677 (CAN) for Website information: www.adfweb.com?Product=HD67678 (CANopen) www.adfweb.com?Product=HD67679 (PROFINET Slave) www.adfweb.com?Product=HD67685...
-
Page 2: Updated Documentation
User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 2 di 33 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX Updated UPDATED DOCUMENTATION... -
Page 3: Security Alert
User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 3 di 33 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation. -
Page 4: Example Of Connection
User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 4 di 33 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 5: Connection Scheme
User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 5 di 33 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67685-IP-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... - Page 6 User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 6 di 33 Industrial Electronic Devices Figure 1b: Connection scheme for HD67685-MSTP-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
- Page 7 User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 7 di 33 Industrial Electronic Devices Figure 1c: Connection scheme for HD67685-MSTP-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
- Page 8 Pagina 8 di 33 Industrial Electronic Devices CHARACTERISTICS: The HD67685-IP-A1, HD67685-MSTP-A1, HD67685-MSTP-B2 is a BACnet Slave / J1939 Converter. It allows the following characteristics: Up to 2048 BACnet objects (Read + Write); Triple isolation between BACnet - Power Supply, BACnet – J1939, Power Supply – J1939.
-
Page 9: Power Supply
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67685-IP-A1 HD67685-MSTP-A1 HD67685-MSTP-B2 Caution: Not reverse the polarity power HD67685-IP-A1 HD67685-MSTP-B2 HD67685-MSTP-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com... -
Page 10: Function Modes
User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 10 di 33 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch A’: The first, with Dip1 in Off position (factory setting), is used for the normal working of the device. The second, with Dip1 in On position, is used for upload the Project/Firmware. - Page 11 Revision 1.001 Pagina 11 di 33 Industrial Electronic Devices LEDS: HD67685-IP-A1 The device has got four LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode...
- Page 12 User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 12 di 33 Industrial Electronic Devices HD67685-MSTP-A1 The device has four LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
- Page 13 User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 13 di 33 Industrial Electronic Devices HD67685-MSTP-B2 The device has five LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
- Page 14 User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 14 di 33 Industrial Electronic Devices J1939: To terminate the J1939 line with a 120Ω resistor it is necessary that the Dip1 of ‘Dip-Switch C’ is at ON position. Cable characteristics: DC parameter: Impedance...
- Page 15 User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 15 di 33 Industrial Electronic Devices ETHERNET: BACnet/IP connection and Ethernet update must be made using Connector3 and/or Connector4 of HD67685 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps.
- Page 16 User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 16 di 33 Industrial Electronic Devices RS485: The RS485 port is present only for the BACnet MS/TP devices (HD67685-MSTP-A1 and HD67685-MSTP-B2). For terminating the CAN line with a 220Ω resistor it is necessary to put Dip1 of ‘Dip-Switch B’ at ON position. The maximum length of the cable should be 1200m (4000 feet).
- Page 17 User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 17 di 33 Industrial Electronic Devices USE OF COMPOSITOR SW67685: To configure the Converter, use the available software that runs with Windows, called SW67685. It is downloadable on the site www.adfweb.com and its operation is described in this document.
-
Page 18: New Configuration / Open Configuration
User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 18 di 33 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device configuration can also be imported or exported: To clone the configurations of a programmable “BACnet Slave / J1939 –... -
Page 19: Software Options
User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 19 di 33 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. - Page 20 User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 20 di 33 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
-
Page 21: Set Communication
User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 21 di 33 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, BACnet and J1939. By Pressing the “Set Communication” button from the main window for SW67685 (Fig. 2) the window “Set Communication”... - Page 22 User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 22 di 33 Industrial Electronic Devices If the field “Enable Peer to Peer” is checked the gateway accept any ID that have the PGN inserted in the section “Receive Frames”. If selected “BACnet MS/TP”, the means of the fields for “BACnet”...
-
Page 23: Receive Frames
User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 23 di 33 Industrial Electronic Devices RECEIVE FRAMES: By pressing the “Receive Frames” button from the main window for SW67685 (Fig. 2) the window “Receive J1939 Frames” appears (Fig. 4). The data of the columns have the following meanings: In the field... -
Page 24: Send Frames
User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 24 di 33 Industrial Electronic Devices SEND FRAMES: By pressing the “Transmit Frames” button from the main window for SW67685 (Fig. 2) the window “Transmit J1939 Frames” appears (Fig. 5). data columns have... - Page 25 User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 25 di 33 Industrial Electronic Devices SET BACNET ACCESS: By Pressing the “Set BACnet Access ” button from the main window for SW67685 (Fig. 2) the window “BACnet Set Access” appears (Fig. The window is divided in two parts, the “BACnet in Read”...
- Page 26 User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 26 di 33 Industrial Electronic Devices Is possible to insert directly the Unit (using its unique number) by compiling the “Selected BACnet Engineering Unit” field; or by selecting with the fields “Select the Type”...
-
Page 27: Update Device
User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 27 di 33 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port. If you don’t know the actual IP address of the device you have to use this procedure: Turn OFF the Device;... - Page 28 User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 28 di 33 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67685 device. Warning: If Fig.
-
Page 29: Mechanical Dimensions
User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 29 di 33 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 10a: Mechanical dimensions scheme for HD67685-xxx-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... - Page 30 User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 30 di 33 Industrial Electronic Devices Figure 10b: Mechanical dimensions scheme for HD67685-MSTP-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
-
Page 31: Ordering Informations
BACnet type IP: BACnet/IP MSTP: BACnet MSTP Device Family HD67685: BACnet slave / J1939 - Converter Order Code: HD67685-IP-A1 BACnet IP Slave / J1939 - Converter HD67685-MSTP-A1 BACnet MSTP Slave / J1939 – Converter HD67685-MSTP-B2 BACnet MSTP Slave / J1939 - Converter... -
Page 32: Other Regulations And Standards
User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 32 di 33 Industrial Electronic Devices DISCLAIMER All technical content within this document can be modified without notice. The content of the document content is a recurring audit. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 33: Warranties And Technical Support
User Manual BACnet Slave / J1939 Document code: MN67685_ENG Revision 1.001 Pagina 33 di 33 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: 1) Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
