Industrial Electronic Devices
CHARACTERISTICS:
The HD67738-xxx-A1 are IEC 61850 / BACnet - Converters.
It allows for the following characteristics:
Triple isolation between RS232/RS485/RS422 - Power Supply, RS232/RS485/RS422 - Ethernet, Ethernet - Power Supply;
Two-directional information between IEC 61850 bus and BACnet bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67738 software on your PC in order to perform the following:
Define the parameters of IEC 61850 line;
Define the parameters of BACnet line;
Define IEC 61850 variables that contains the data written by the BACnet Master;
Define IEC 61850 variables that contains the data to make available to the BACnet Master;
Define BACnet objects accessible by the external BACnet Master;
Export the EDE file for configuration of BACnet Master;
Update the device.
ADFweb.com S.r.l.
User Manual IEC 61850 Server / BACnet Slave
Document code: MN67738_ENG
Revision 1.000
Page 7 of 30
