IEC 61850 S :
ERVER
This section is used to define the main parameters of IEC 61850 line. The means of
the fields are:
In the field "Port" the port used for IEC 61850 communication is defined;
If the field "Password" the password used for accessing to IEC 61850
variables is defined.
TLS (T L S
RANSPORT AYER ECURITY
This section is used to define the main parameters of TLS protocol. The means of
the fields are:
If the field "Enable TLS" is checked, the TLS protocol for secure connection
is enabled;
In the field "Key" the key for the authentication is defined;
In the field "Key Password" the password for decrypting the key is defined;
In the field "Server Certificate" the certificate for the server is defined;
In the field "Root Certificate" the root of the server is defined;
If the field "Enable Only Known
accept just connection from known Clients (defined in the section "TLS
Known Certificate").
ADFweb.com S.r.l.
) S
ERVER
Certificates" is checked, the converter will
User Manual IEC 61850 Server / BACnet Slave
Document code: MN67738_ENG Revision 1.000
Figure 3b: "Set Communication
Server" window
Figure 3c: "Set Communication
Page 18 of 30
 IEC 61850
 TLS" window
