How to use the Cut & Store Program:
Turn on the power to the cutter, wait until the backgauge moves back and will
recalibrate the position and this display appears:
NOTE: There will be a cursor (❑) flashing over at the last number, this is the work area.
C: 26"125
1: 00"00❑
Select a program number from 1-9, if you press (PROG)+(2) this screen appears:
C: 26"000
1: 00"00❑
By pressing
CUT &
STORE
C: 26"000
1: 00"000
Use the manual keys
to the first cut position, say 15.0". Then make a cut and this screen appears:
C: 15"000
1: 15"000
Move the backgauge to the second cut position, say 14.5" then make a cut and
the following screen appears:
C: 14"500
3: 00"00❑
PROG: 1
2: 00"000
PROG: 2
2: 00"000
, the following screen appears:
PROG: 2 C&S
2: 00"000
FAST SLOW FAST
FWD FWD REV
PROG: 2 C&S
2: 00"00❑
PROG: 2 C&S
4: 00"000
SLOW
, to move the backgauge
REV
12
