Duplo Programatic Mark - II Operation Manual page 18

Press (END) it will beep 4 times, then re-press (END) to store the program and the
screen will change to:
C: 26"125
1: 08"75❑
If you want to make a cut, press (AUTO) , the backgauge will move to 8.75" position and
the following screen appears:
C: 08"750
1: 08"75❑
Make the first cut and the backgauge moves in forward 2.0", the following is on the
screen:
C: 06"750
3: − 00"25❑ 4: ×
After the second cut is made, the backgauge moves in forward 0.25" and the following
appears:
C: 06"500
3: − 00"25❑
After you finish your 2.0" x 4 pieces & 0.25" x 3 trims, the backgauge moves to the first
cut position at 8.75", then you can make the second cycle cut:
C: 08"750
1: 08"75❑
After you have finished all cuts, press (AUTO) to remove the automatic backgauge
movement, AUTO will disappear on the display, and this screen appears:
C: 08"750
1: 08"75❑
NOTE: If you want to correct the programmed cut positions, press keys (LAST)
and (NEXT) to move the black square to the position which require, and re-enter
new cut sizes, then press (NEXT).
PROG: 4
2: − 02"000
PROG: 4 AUTO
2: − 02"000
PROG: 4 AUTO
03
PROG: 4 AUTO
4: ×
03
PROG: 4 AUTO
2 : − 02"000
PROG: 4
2: − 02"000
17
