Duplo Programatic Mark - II Operation Manual page 9

: Slow reverse. When the key is pressed and held down, the backgauge
SLOW
REV
moves slowly to the rear and stops at the rear point, after the key is
released the backgauge moves forward 2 mm automatically.
: Brake Release. 660 model: The key need not be pressed, just push
BRAKE
RELS
in the hand wheel and then you can make a micro adjustment. On the 486
model: when you make micro a adjustment you need to press & hold down this key.
: Cut & Store. First select the program number, then press (CUT &
CUT &
STORE
STORE), the screen shows C & S. You can now setup the required cut
size by pressing (FWD/REV) keys and using the hand wheel. When the cut size is
selected, make a cut and the cut position will be stored automatically.
: Auto. You have to confirm the start position of the shift before this key
AUTO
is pressed. Press the key, it will store the desired cut positions in order.
: Run. In AUTO mode, press (RUN), it will run (or skip) over a certain
RUN
cut size which is not used, and will go to the next cut in memory.
: Minus ( − ) can be used together with Multiplication ( × ). These
− ×
keys are used for making multiple cuts into more pieces (i.e. business
cards).
8
