Duplo Programatic Mark - II Operation Manual page 11

If you want to make 3 cuts, the first cut is at 17.0", the second cut at 15.5", and the last
cut at 15.0", follow the procedure as listed below:
Press (1)+(7)+(0)+(0)+(0) (NEXT) , the following screen appears:
C: 26"125
1: 17"000
Press (1)+(5)+(5)+(0)+(0) (NEXT) screen appears:
C: 26"125
3: 00"00❑
Press (1)+(5)+(0)+(0)+(0) (NEXT) and screen appears:
C: 26"125
3: 15"000
Press (END) and it will beep 4 times, then re-press (END) to store the program, then the
screen will change to:
C: 26"125
1: 17"00❑
If you want to start cutting, press (AUTO) , and backgauge will move to the first cut
position and the following screen appears:
C: 17"000
1: 17"00❑
Place your paper and make the first cut, after completing the cut, the backgauge moves to
the second cut position.
Adjust the paper for the 2
rd
3 cut position.
Adjust the paper for the 3
your stack automatically. Then it moves to the first cut position and readies itself for the
next cut cycle.
PROG: 1
2: 00"00❑
PROG: 1
4: 00"000
PROG: 1
4: 00"00❑
PROG: 1
2: 15"500
PROG: 1 AUTO
2: 15"500
nd
cut, after completing the cut, the backgauge will move to the
rd
cut & make your cut, the backgauge will then "push-out"
10
